Nickel Plated Brass Cable Glands
1.Material:Body:nickel-plated brass Seal:Polyamide 66,Sealing:NBR
2.Protection degree: With the Clamping range,its protection degree can reach IP68.
3.Properties:pass ROHS
4.Temperature Range: Stat: Min. -40C,Max. 100C,Short-term 120C
Dyn:Min. -20C,Max. 80C,Short-term 100C
| Thread | Spec. | Cable Range (mm) |
Thread Length (mm) |
Wrench Size (mm) |
Thread | Spec. | Cable Range (mm) |
Thread Length (mm) |
Wrench Size (mm) |
| M | M8*1.25 | 3-4.5 | 5.5 | 11 | PG7 | 3-7 | 6 | 14 | |
| M8*1 | 3-7 | 6 | 14 | PG | PG9 | 4-8 | 7 | 17 | |
| M10*1 | 3-7 | 6 | 14 | PG11 | 6-10 | 7 | 20 | ||
| M12*1.5 | 3-7 | 6 | 14 | PG13.5 | 8-12 | 8 | 22 | ||
| M14*1.5 | 3-7 | 6 | 14/16 | PG16 | 10-14 | 8 | 24 | ||
| M16*1.5 | 4-8 | 7 | 17/18 | PG19 | 10-14 | 8 | 24/27 | ||
| M18*1.5 | 6-10 | 7 | 20 | PG21 | 13-18 | 8 | 30 | ||
| M20*1.5 | 8-12 | 8 | 22 | PG25 | 15-22 | 9 | 34 | ||
| M22*1.5 | 10-14 | 8 | 24 | PG29 | 18-25 | 9 | 40 | ||
| M24*1.5 | 10-14 | 8 | 24/27 | PG36 | 25-32 | 10 | 50 | ||
| M25*1.5 | 10-14 | 8 | 24/27 | PG42 | 32-38 | 10 | 58 | ||
| M27*1.5(2) | 13-18 | 8 | 30 | PG48 | 37-44 | 12 | 64 | ||
| M30*1.5(2) | 13-18 | 8 | 28/34 | PG63 | 42-52 | 15 | 76/78 | ||
| M32*1.5(2) | 15-22 | 9 | 34 | ||||||
| M33*1.5(2) | 15-22 | 9 | 34/36 | G | G1/4" | 3-7 | 6 | 14 | |
| M36*1.5(2) | 18-25 | 9 | 40 | G3/8" | 4-8 | 7 | 17/18 | ||
| M37*1.5(2) | 18-25 | 9 | 40 | G1/2" | 8-12 | 8 | 22 | ||
| M40*1.5(2) | 22-28 | 10 | 43 | G3/4" | 13-18 | 8 | 30 | ||
| M42*1.5(2) | 22-28 | 10 | 43/45 | G1" | 15-22 | 9 | 34/36 | ||
| M48*1.5(2) | 25-32 | 10 | 50/52 | G1-1/4" | 22-28 | 10 | 43/45 | ||
| M50*1.5(2) | 25-32 | 10 | 50/55 | G1-1/4" | 22-30 | 10 | 43/45 | ||
| M54*1.5(2) | 32-38 | 12 | 58 | G1-1/2" | 25-32 | 10 | 50/52 | ||
| M56*1.5(2) | 32-38 | 12 | 58 | G2" | 37-44 | 12 | 64 | ||
| M60*1.5(2) | 37-44 | 12 | 64 | G2-1/2" | 42-52 | 15 | 76/78 | ||
| M63*1.5(2) | 37-44 | 12 | 64/68 | G3" | 65-70 | 18 | 98 | ||
| M64*1.5(2) | 37-44 | 12 | 64/68 | NPT | NPT1/4" | 3-7 | 6 | 14 | |
| M72*1.5(2) | 42-52 | 15 | 76/78 | NPT3/8" | 4-8 | 7 | 18 | ||
| M75*1.5(2) | 42-52 | 15 | 76/78 | NPT1/2" | 8-12 | 8 | 22 | ||
| M76*1.5(2) | 42-52 | 15 | 76/78 | NPT3/4" | 13-18 | 8 | 30 | ||
| M80*1.5(2) | 50-62 | 16 | 86/88 | NPT1" | 15-22 | 9 | 36 | ||
| M85*1.5(2) | 50-62 | 16 | 86/88 | NPT1-1/4" | 22-28 | 10 | 45 | ||
| M85*1.5(2) | 60-70 | 18 | 98 | NPT1-1/4" | 22-30 | 10 | 45 | ||
| M88*1.5(2) | 60-70 | 18 | 98 | NPT1-1/2" | 25-32 | 10 | 50 | ||
| M90*1.5(2) | 60-70 | 18 | 98 | NPT2" | 37-44 | 12 | 64 | ||
| M100*1.5(2) | 70-80 | 20 | 110 | NPT2-1/2" | 42-52 | 15 | 78 | ||
| NPT3" | 60-70 | 18 | 98 | ||||||
.
Why Chose Us?
1.We are factory,the price are competitive.
2.Good quality,the goods are passed UL,ROHS,CE,SGS,CCS ect. They have been exported to many countries and enjoy good popularity.
3.Quickly delivery,we have automatic production line,so the production is much quicker. Keep smooth delivery on time.
4.Perfect package according your demand
5.We have design/technology team and can make new products according your demand.
Trade team of products
1.Payment:T/T,L/C,D/A,D/P ,Western Union,Paypal etc.
2.Supply Ability:20ft Container/Month
3.OEM: accept
4.Delivery: •By Courier: 1-2 Working days by special offer
•By Air: 4-7 Working days at appointed airport
•By Sea:20-25 Working days at appointed port
Package of products
•Common Packing:100Pcs+Polybag+Label+Export Carton
•Customized Packing:Header card packing,Blister with card packing,Double Blister packing,Canister packing,other packing can be supplied according customers requirement.
Services
Excellent service and first-class after-sale service
•Provide professional sale person to communicate with you before the order
•Provide optimum system solution based on each client’s export
•Provide strict check for each part,each process before export.
•Provide post-sale service,including installation,technical guide and training.
If you are interested in our products, please contact with us. Thank you.
