Specifications
1,SDI converter2,1080p/60fps, 1080i/60fps, 720p/25fps
3,cheap. practical
The future of video collaboration is now
Our new products and solutions have begun to transform the industry by redefine the video collaboration experience as we know it
SDI to SDI Repeater
SDI to HDMI Converter
HDMI to SDI Converter
Please confirm the resolution of Input/Output as the last page before using
1. Equipment
2. Installation Instruction
SDI Repeater:
SDI IN |
SDI Input |
SDI OUT |
SDI Output |
DC IN 12V |
DC 12V, 0.5A Input socket |
STATUS |
On: signal connected Off: Signal Unconnected |
HDMI to SDI Converter:
SDI OUT |
SDI Input |
DC IN 12V |
DC 12V, 0.5A Output Socket |
STATUS |
On: Signal connected Off: Signal unconnected |
HDMI IN |
HDMI Input |
SDI to HDMI Converter | |
Input |
HD-SDI: BNC (SMPTE-292M/296M Compliant) |
Output |
HDMI |
Resolution |
1080p/60fps, 1080p/50fps, 1080p/30fps, 1080p/25fps, 1080i/60fps, 1080i/50fps, 1080i/30fps, 1080i/25fps, 720p/60fps, 720p/50fps, 720p/30fps, 720p/25fps |
Power |
12VDC Regulated, Max. 6W |
Dimension (HxWxD) |
82.8 x 25.2 x 79.5mm |
Weight |
199 g |
Working Temperature |
0~40°C |
|
|
|
|
|
|
HDMI to SDI Converter | |
Input |
HDMI |
Output |
HD-SDI: BNC x 2 (SMPTE-292M/296M Compliant) |
Resolution |
1080p/60fps, 1080p/50fps, 1080p/30fps, 1080p/25fps, 1080i/60fps, 1080i/50fps, 1080i/30fps, 1080i/25fps, 720p/60fps, 720p/50fps, 720p/30fps, 720p/25fps |
Power |
12VDC Regulated, Max. 6W |
Dimension(HxWxD) |
82.8 x 25.2 x 79.5mm |
Weight |
199 g |
Working Temperature |
0~40°C |
|
|
|
|
SDI to SDI Repeater | |
Input |
HD-SDI: BNC (SMPTE-292M/296M Compliant) |
Output |
HD-SDI: BNC x 2 (SMPTE-292M/296M Compliant) |
Resolution |
1.485Gbps |
Power |
1080p/60fps, 1080p/50fps, 1080p/30fps, 1080p/25fps, 1080i/60fps, 1080i/50fps, 1080i/30fps, 1080i/25fps, 720p/60fps, 720p/50fps, 720p/30fps, 720p/25fps |
Dimension(HxWxD) |
12VDC Regulated, Max. 6W |
Weight |
82.8 x 25.2 x 79.5mm |
Working Temperature |
217 g |
Output |
0~40°C |
