USB SDI WLAN Video Conference Camera Using With Newtek Tricaster

USB SDI WLAN Video Conference Camera Using With Newtek Tricaster thumbnail-1
USB SDI WLAN Video Conference Camera Using With Newtek Tricaster thumbnail-2
USB SDI WLAN Video Conference Camera Using With Newtek Tricaster thumbnail-3
USB SDI WLAN Video Conference Camera Using With Newtek Tricaster thumbnail-4
USB SDI WLAN Video Conference Camera Using With Newtek Tricaster thumbnail-5
USB SDI WLAN Video Conference Camera Using With Newtek Tricaster thumbnail-6
USB SDI WLAN Video Conference Camera Using With Newtek Tricaster photo-1
USB SDI WLAN Video Conference Camera Using With Newtek Tricaster photo-2
USB SDI WLAN Video Conference Camera Using With Newtek Tricaster photo-3
USB SDI WLAN Video Conference Camera Using With Newtek Tricaster photo-4
USB SDI WLAN Video Conference Camera Using With Newtek Tricaster photo-5
USB SDI WLAN Video Conference Camera Using With Newtek Tricaster photo-6
US$ 1 - 10 MOQ: 1 Piece
Key Specifications
Get Latest Price
Type:
Video Conference System
Function:
Other, video camera
Simultaneous Interpretation:
No
Contact Supplier Request Quote Chat Now
Shenzhen KATO Vision Co., Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Video Conference System
Function Other, video camera
Simultaneous Interpretation No
Place of Origin Guangdong, China
Brand Name KATO VISION
Model Number KT-HD60US

USB SDI WLAN video conference camera using with Newtek Tricaster

Detailed Images

 USB SDI WLAN video conference camera using with Newtek TricasterUSB SDI WLAN video conference camera using with Newtek Tricaster

USB SDI WLAN video conference camera using with Newtek TricasterUSB SDI WLAN video conference camera using with Newtek Tricaster

USB SDI WLAN video conference camera using with Newtek Tricaster

Product Description



Item No.

KT-HD60US

Image Sensor

1/2.8’’Progressive CMOS

Effective Pixels

3.5 Megapixels

Resolution HD

1080p60/50,1080i60/50,1080p30/25,720p60/50

Signal System

PAL/NTSC

Lens

20X optical zoom, f=4.7mm(wide angle end)~94.0 mm(far end)

Horizontal View Angle

58.7°(W)~3.2°(T)

Focus System

Auto/Manual

Minimum Illumination

0.5Lux

Exposure Control

Auto/Manual/Priority AE/Exposure Compensation/ Bright

Shutter Speed

1/1~1/10,000s

Gain

Auto/Manual

White Balance

Auto/ Indoor/Outdoor/Manual

Image Effect

Full color/black and white/Electronic flip

S/N Ratio

≥50db

Pan

355°(max. speed:80°/s)

Tilt

-30° to +90° (max. speed: 60°/s)

Preset Position

9 preset positions by IR remote controller, 255 preset positions by Keyboard

Output

USB2.0+SDI+RJ45(Optional)

Control Protocol

SONY VISCA, PELCO P/D

Control Mode

RS-232C, RS-422/485

Power

12V  DC(10.8~13.0V DC)

Power Consumption

Max. 30W(DC 12V)

Operating Temperature

0~40℃

Storage Temperature

-20-60℃

Dimensions

(L)170×(W)150×(H)190mm

Weight

1550g

Color

Black/White

Accessories

DC 12V power adapter, IR Remote, Operation manual, RS-232C Cable, DVI adapter, YPbPr/HDMI cable, Ceiling bracket
