18x ptz Video Conferencing System for small groups
We KATA VISION, which is a professional Video Conference Camera R&D manufacturer for 12 years, established in 2004. Main product include SD/HD/USB Video Conference Camera, Capture Card, Microphone and any Accessories etc. All product passed the CE, FCC, CCC, UL, ROHS Certificates.
Item No. | KT-D848 |
Image Sensor | SONY 1/4 Exwave HAD CCD |
Effective Pixel | 752 (H) * 582 (V) |
Signal System | NTSC/PAL |
Horizontal Resolution | 550 TVL |
Synchronization | Internal & External |
Lens | 18* Optical, F=4.1mm(tele)~73.8mm(wide), F1.4~F3.0 |
Angle of View (H) | 48°(wide-angle)~2.8°(far-end) |
Min. object distance | 290mm(wide-angle)~800mm(tel-end) |
Minimum Illumination | 0.4lux (F1.4, 50IRE) |
Auto exposure | Auto/Manual/AE priority/Exposure compensation/Backlight compensation |
Shutter Speed | 1/3~1/10000S,22 shelves |
Gain | Auto/Manual (-3 ~ +28dB, 16 steps) |
White Balance | Auto/Indoor/Outdoor/One push WB/Manual WB |
S/N Ratio | more than 50dB |
Pan/Tilt | Pan: +/- 360° (max. speed: 80°/s) Tilt: -30° to + 90° (max. speed: 60°/s) |
Preset Position | 9 by remote commander, 256 by keyboard controller |
Picture effect | E-Flip, Invert, Mirror |
Analog Output | VIDEO and S-VIDEO VBS 1.0VP-P |
Camera Control | RS-232C(8-pin DIN)/(VISCA)/RS-422(9-pin) (VISCA) |
Baud rate | 9600bps, 38400bps |
Power | 10.8V~13.2V |
Operating Temperature | 0℃~50℃ |
Storage Temperature | -20℃~+60℃ |
Consumption | 12W |
Dimensions | (L)153*(W)134*(H)153mm |
Weight | 1200g |
Color | black |
