Home > Products > Stainless steel welded tube / pipe > Stainless Steel round Welded Tube
Stainless Steel round Welded Tube
- 30000 Ton / Tons per Month
- Guangzhou /Shenzhen
- T/T
Product Details
Standard: | ASTM, AISI, DIN, EN, GB, JIS | Place of Origin: | Guangdong, China | Brand Name: | xinya |
Model Number: | cold drawing | Type: | Welded | Steel Grade: | 200 Series |
Application: | BUILDING MATERIAL,ORNAMENTAL TUBING | Certification: | ISO | Welding Line Type: | ERW |
Thickness: | 0.2MM-3.0mm | Outer Diameter: | 8~219MM |
Product Description
Our products are all made of quality raw materials, and are in the lead of the industry in pipe making precision and technological level. Our products have the advantages of fine workmanship, high corrosion-resistance and luster , good bending strength, elegance, sturdiness and durability ,etc.
Xinya sus201/304 pipe are strictly and precisely made with national standard quality raw materials.
Xinya sus201/304pipe fully meet standards, as strictly tested by national authoritative testing organizations and tested by technical and quality supervision departments at irregular intervals.
Xinya sus201/304 pipe features fine workmanship, high glossiness and excellent corrosion-resistance and mechanical performance.
Xinya sus201/304 pipe rely on excellent quality to be specially supplied to coastal regions , large municipal works and civil home furnishing projects.
The specifications our company can produce
Quick Details
Standard:JIS,AISI,ASTM,GB
Place of Origin:Guangdong, China (Mainland)
Brand Name:XINYA,GUANHANG
Model Number:SS 201 304 430
Type:Welded
Steel Grade:200 Series
Application:Window,Door,Handrail.etc
Certification:ISO
Welding Line Type:ERW
Thickness:0.24mm---3mm
Outer Diameter:16mm---89mm,16x16mm---80x80mm,25x13mm---75x45mm
Polish:Grit 600
Length:Regular 6000mm.Customized 3000 to 6100mm
Process:Annealing. Bend test
Packaging & Delivery
Packaging Details: | PVC bag.Bundle.Customized. |
Delivery Detail: | Below 50 tons,within 15 days. |
Specifications
Professional quality stainless steel empaistic tubes,we focus on the producing process and are strict on the quality.
Detailed Product Description
We are manufacturer of stainless steel pipes. Have 8 years in exporting. Xinya , you should be dependent on the brand!
FoShan XinYa Stainless Steel Co., Ltd is a professional manufactory specialized in stainless steel pipe online for many years in China. XinYa has passed ISO9001. In addition, we have customers all over the world, and we have good long-term healthy relatio
ns with them. That proves our quality products and service.
Standard:
Strictly follow the ASTM A 554 and others.
Features:
1) Material of stainless steel: grade: AISI 201, 304 430
2) Applied field: construction upholstery, and industry instruments (fencing, railing, security doors / windows, gate fittings, inside staircases, balcony balustrades,furniture, sanitary wares, kitchen wares)
Specifications:
1) Round pipes - Outside diameter(mm) :
8,9.5,11,12, 12.7,14.5, 15.9, 17,18,19,20,22,23,28,29, 31.8 ,35,36,38,45, 47,48,50.8,60,63,76,88.9,102,114,133,141,159,219
2)Square pipes - Outside dimensions(mm) : 10x10,12x12,15x15,17x17,18x18,19x19,20x20,22x22,23x23,24x24,25x25,28x28,30x30,36x36,38x38,40x40,48x48,50x50,60x60,70x70,80x80
3)Rectangular pipes - Outside dimensions(mm) : 20x10,23x11,24x12,25x13,28x13,30x15,34x22,36x23,37x24,38x25,40x20,48x23,50x15,50x25,60x15,60x30,73x43,75x45,95x45
4) Wall thickness: 0.24- 3.0mm
5) Length: 6m (or according to customers' requests)
6) Polishing: 600#,400#, 320#, 240#, 180#.etc.
7) Tolerance:
a) Outer diameter: ±0.15mm
b) Thickness: ±10% of wall thickness
c) Length: ±4.5mm - 0mm
8) Other size can be manufactured according to requirements
