Home > Electrical & Electronics > Telecommunication & Broadcasting > Fiber Optic Equipment > UART to WiFi Module RS232 to Ethernet WiFi Serial Adapter

UART to WiFi Module RS232 to Ethernet WiFi Serial Adapter

Name: UART to WiFi Module RS232 to Ethernet WiFi Serial Adapter
Brand: Blueone/ Neutral/ Customized
SKU: 112794147
Availability: InStock

UART to WiFi Module RS232 to Ethernet WiFi Serial Adapter thumbnail-1

UART to WiFi Module RS232 to Ethernet WiFi Serial Adapter thumbnail-2

UART to WiFi Module RS232 to Ethernet WiFi Serial Adapter photo-1

UART to WiFi Module RS232 to Ethernet WiFi Serial Adapter photo-2

US$ 30 - 50 MOQ: 5 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Guangdong, China

Brand Name:

Blueone/ Neutral/ Customized

Model Number:

WSS900

Contact Supplier Request Quote Chat Now

Shenzhen Blueone Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Guangdong, China

Brand Name Blueone/ Neutral/ Customized

Model Number WSS900

UART to WiFi Module RS232 to Ethernet WiFi Serial Adapter

Product Description

WiFi Serial Device Server is a wireless device which converts RS232/485 serial into WiFi or Ethernet, thus realizes two-way transparent transmission between the computer and RS232/485 devices over the Internet.

Through WiFi serial device server, serial port devices with RS232/485 can be connected to the Internet over WiFi or Ethernet cable.

Thus, you can easily manage these serial devices from a computer over the Internet remotely.

Superstrong stability

High processing speed

Fast detection of disconnection

Strong WiFi connection

RS232 and RS485 two ports work simultaneoulsy

WiFi and LAN work simultaneously

No need install drive, easy to operate

Advantages

1. Traditional Serial device server composed by singlechip and WiFi module works not steadily. It even cannot work normally especially when there are big network data. Therefore, our company released newest serial device server based on Linux OS which solved above problems and provide steady data transmitting.

2. This serial device server is integrated with php5.5 frame which is convenient for secondary development and extensive applications.

3. New functions can be updated remotely by upgrading firmware, no need change the hardware, which help you to save cost.

4. No need install drive. The software is very easy to operate.

Technical Specs

System Hardware Information
Processor	Embedded MIPS24KEc
Working frequency	580Mhz
Memory	128MBytes DDR2
Flash	32MBytes
Network	1 10M/100M
WIFI	802.11n 2.4 GHz 150M
Emission power	16.5DB
RS232/RS485	2 Channel
Bluetooth Connect	7 Channel (Optional)
Power Input	DC 9~28V
Power consumption	1A/12V
Working temperature	-20~80℃
Storage temperature	-30 ~85℃
5 - 95%RH
Package Size
Certification	FCC/CE
Network parameters
Speed	10/100M Auto
Electromagnetic isolation	2KV
Network Protocol	IP/TCP/UDP/DHCP/DHCPD/DNS/HTTP/SNMP
MAX TCP Connectors	4096
SDK Soft	PHP5.5
WiFi parameters
Setting Mode	Software / Webserver
Frequency	2.4G
Interface	SMA RF Antenna
Transmission power	+16.5 DB (802.11n)
Sensitivity	-75DB (802.11n)
Encryption	WPA/WPA2 TKIP/AES
Transmission Distance	200 meters
Work Mode	Station/AP
User Number	MAX 120
WiFi parameters
Frequency	2.4G
Interface	SMA RF Antenna
Transmission power	+16.5 DB (802.11n)
Sensitivity	-75DB (802.11n)
Encryption	WPA/WPA2 TKIP/AES
Transmission Distance	200 meters
Work Mode	Station/AP
User Number	MAX 120
UART RS232 Information
RS232 Port	1
Baud rate	300~230400BPS
Data bit	5/6/7/8 Bits
Stop Bit	1/2 Bits
Check	None/Odd/Event
Buffer Size	4MBytes
Interface	DB9 Female Head and Male Pin
UART RS485 Information
RS485 Port	1
Baud rate	300~230400BPS
Data bit	5/6/7/8 Bits
Stop Bit	1/2 Bits
Check	None/Odd/Event
Buffer Size	4MBytes
Interface	Two Line (A,B)

Applications

- Access control system

- Attendance system

- Vending system

- POS system

- Building automatically system

- Self-service bank system

- Telecommunication operating room monitoring system

- Electrical power monitoring and controlling

Software

Our Services

~ Blueone products enjoy high quality and perfect after-sale services

~ Blueone provide quick shipment via various ways( DHL, UPS, FedEx, TNT, EMS, sea transportation, air transportation)

~ Blueone provide professional technical support and customized services

~ Free firmware upgrading

~ One year warranty

Payment methods: TT, Paypal, Western Union

Contacts

Need any more details about our Serial Device Server, please contact us freely. Your inquiry will get reply immediately or within 12 hours if it is not our working time. Thank you for kind cooperation!
