ND2282 leadshine 110 volt ac nema 52 stepper motor controller
The ND2282 is a high performance and low noise microstepping driver based on pure-sinusoidal current control technology. It’s suitable for driving 2-phase and 4-phase hybrid stepping motors. By using advanced bipolar constant-current chopping technique, the ND2282 can output more torque than other drivers at high speed. The microstep capability allows stepping motors to run at higher smoothness, less vibration and lower noise. Its pure-sinusoidal current control technology allows coil current to be well controlled with relatively small current ripple, therefore smaller motor noise and less motor heating can be achieved. In addition, the ND2282 has a built-in EMI filter which can make the driver operate with higher reliability.
Features
High quality, cost-effective
Low motor noise and heating
Supply voltage up to 220VAC (310VDC)
Output current up to 8.2A(5.86 ARMS)
TTL compatible and Opto-isolated inputs
Automatic idle-current reduction
Input frequency up to 200KHz
15 microstep resolutions selectable
Suitable for 2-phase and 4-phase stepping motors
DIP switch microstep & current settings
Support PUL/DIR & CW/CCW modes
Specifications
Parameters |
ND2282 |
|||
Min |
Typical |
Max |
Unit |
|
Output current |
0.7(0.5A RMS) |
- |
8.2 (5.86 RMS) |
A |
Supply voltage |
90(125) |
180(250) |
220(310) |
VAC(VDC) |
Logic signal current |
7 |
10 |
16 |
mA |
Pulse input frequency |
0 |
- |
200 |
kHz |
Isolation resistance |
500 |
- |
- |
Mohm |
Product photos
Similar items
| ND1182 | 2ph | 0.7~8.2A | 70~150VAC | Matching Nema34 42 Motor | |
| ND2282 | 2ph | 0.7~8.2A | 90~220VAC | Matching Nema34 42 52 Motor | |
| 3ND583 | 3ph | 2.1~8.3A | 18~50VDC | Matching Nema23 34 Motor | |
| 3ND583B | 3ph | 2.2~8.3A | 20~50VDC | Matching Nema23 34 Motor | Laser Cutting Machine |
| 3ND1183 | 3ph | 2~8.2A | 80~150VAC | Matching Nema34 42 Motor | |
| 3ND2283 | 3ph | 2~8.2A | 150~220VAC | Matching Nema34 42 Motor | |
| 3ND2283-600 | 3ph | 2~8.2A | 150~220VAC | Matching Nema43 52 Motor |
