Toauto 9kw 12000 rpm spindle motor GDZ143x133-9(380V short head) replace italy hsd
Specification(Air cooled spindle motor)
| Model | Speed | Power | Torque | Voltage | Current | Frequency |
| GDZ93x82-1.5(220V) | 18000rpm | 1.5KW | 0.81NM | 220V | 6.8A | 300Hz |
| GDZ93x82-1.5(380V) | 18000rpm | 1.5KW | 0.81NM | 380V | 3.8A | 300Hz |
| GDZ93x82-2.2(220V) | 18000rpm | 2.2KW | 1.21NM | 220V | 10A | 300Hz |
| GDZ93x82-2.2(380V) | 18000rpm | 2.2KW | 1.21NM | 380V | 5.5A | 300Hz |
| GDZ93x82-3.5(220V) | 18000rpm | 3.5KW | 1.92NM | 220V | 15A | 300Hz |
| GDZ93x82-3.5(380V) | 18000rpm | 3.5KW | 1.92NM | 380V | 8.8A | 300Hz |
| GDZ120x103-4.5 | 18000rpm | 4.5KW | 2.45NM | 380V | 9.5A | 300Hz |
| GDZ120x103-6 | 18000rpm | 6KW | 3.21NM | 380V | 12.6A | 300Hz |
| GDZ120x103-7.5 | 18000rpm | 7.5KW | 380V | 15.5A | 300Hz | |
| GDZ170x150-12 | 18000rpm | 12KW | 380V | 26A | 300Hz | |
| GDZ70X65-350(220V) | 12000rpm | 350W | 220V | 1.8A | 200Hz | |
| GDZ70X65-350(380V) | 12000rpm | 350W | 380V | 1.1A | 200Hz | |
| GDZ70X65-700(220V) | 18000rpm | 700W | 220V | 3.7A | 300Hz | |
| GDZ70X65-700(380V) | 18000rpm | 700W | 380V | 2.2A | 300Hz | |
| GDZ70X65-750 | 18000rpm | 750W | 220V/380V | 3.9/2.3A | 300Hz | |
| GDZ65F-800 | 24000rpm | 800W | 0.33NM | 220V | 4A | 400Hz |
| GDZ80-1.5F | 24000rpm | 1.5KW | 0.91NM | 220V | 5A | 400Hz |
| GDZ80-2.2F(220V) | 24000rpm | 2.2KW | 0.91NM | 220V | 5A | 400Hz |
| GDZ143x133-8 | 12000rpm | 8KW | 6.4NM | 380V | 18A | 200/400Hz |
| GDZ143x133-9(380V Long head) | 12000~24000rpm | 9KW | 6.4NM | 380V | 22A | 200/400Hz |
| GDZ143x133-9(220V Long head) | 12000~24000rpm | 9KW | 6.4NM | 220V | 200/400Hz | |
| GDZ143x133-9(220V short head) | 12000~24000rpm | 9KW | 6.4NM | 220V | 200/400Hz | |
| GDZ143x133-9(380V short head) | 12000~24000rpm | 9KW | 6.4NM | 380V | 22A | 200/400Hz |
Product photos
