Help CenterTDP 6 Single Punch Tablet Press With 1 Set Free Round Die
Related Products
-
Water Softdrink Liquid Filling MachineUS$ 120 - 170MOQ: 1 Set -
Brand New Double Heads Pneumatic Liquid Filling Machine(30~500ml)NegotiableMOQ: 1 Set
-
Yason Ultrasonic Tube Sealing Machine for Soft Plastic Tube aUS$ 1,200 - 1,500MOQ: 1 Set
-
Numerical Control Hydrator Filler, Liquid Filling Machine (3-3000ml) GFK-160US$ 100 - 188MOQ: 1 Set
-
A03 Manual Filling Machine(5-50ml) for Cosmetic,cream,shapooUS$ 100 - 199MOQ: 1 Set
Specifications
The machine is suitable for the industries of Chemical, Foodstuff,Electronic and etc.♥ TDP 6 Single punch tablet press with 1 set free round die♥
Place of Origin: Guangdong China (Mainland)
Type: Single Punch
Brand Name: OEM
Model Number: TDP6
Type: Tablet Pressing Machine
Application: Tablet
Voltage:: 110V or 220V or 240v or 380v or any Voltage customized
Max.Main Pressure (kn) : 60
Max.Pressure Diameter(mm) : 25
Max.Filling Depth(mm) : 18
Max.Tablet Thickness(mm) : 7.5
Max. Production capacity (p/h) : 3000
Motor (KW) : 1.1
Outside size(mm) : 700X380X695mm
Weight (kg) : 165
The machine is suitable for the industries of Chemical, Foodstuff,Electronic and etc.It is used of pressing medicinal tablets,catalysts,sugar tablets,Calcium tablets,Coffee tablets,Powder Metallurgical,Electronic elements and various tablets of pesticide and fertilizer.etc.in such small-batch production,laboratory and hospital fields.Meanwhile,that machine also can press various abnormity and normal tablet,and press the tablets in two sides with printing as well.
Main Technical Parameters:
Material: Metal and Aluminum.
Model: |
TDP-1.5A |
TDP-1.5 |
TDP-5 |
TDP-6 |
Max.Main Pressure (kn) |
15 |
15 |
50 |
60 |
Max.Pressure Diameter(mm) |
12 |
12 |
20 |
25 |
Max.Filling Depth(mm) |
12 |
12 |
16 |
18 |
Max.Tablet Thickness(mm) |
6 |
6 |
6 |
7.5 |
Max. Production capacity (p/h) |
5000 |
4500 |
4000 |
3000 |
Motor (KW) |
0.55 |
0.55 |
0.75 |
1.1 |
Outside size(mm) |
570×380×630mm |
570×380×630mm |
700X380X695mm |
700X380X695mm |
Weight (kg) |
90 |
90 |
120 |
165 |
