Specifications
This machine is used to carry out sugarcoating and film coating to the core of Chinese Traditional and Western Medicine tabletsSugar Coating Machine Tablet Coating Machine Pill Coater Machine
♥Description♥
This machine has advantages of simplified operation, smooth, fine and bright tablet surface, saving accessories and convenient maintenance.
This machine is used to carry out sugarcoating and film coating to the core of Chinese Traditional and Western Medicine tablets, it integrates strong power, weak power, hydraulic and pneumatic. It is a new type equipment improved on the basis of original common type sugarcoating machine.
♥Instruction♥
It is composed of the mainframe (original sugarcoating machine), controllable normal temperature hot air system, automatic fluid supply and air supply spraying system, etc. The speed can be controlled, the coating accessories using high atomization spray to tablets surface by the method of automatic electrical control. Meanwhile, the tablets make continuous and complex track movement in the coating pan, let the coating fluid cover the tablet core evenly, the controllable normal-temperature hot air in the pan will dry the tablets at the same time, let the tablet rapidly form a firm, fine, complete and smooth surface film.
♥Features♥
·Able to be matched with frequency controller.
·This coating pan is made of stainless steel , the complete machine transmission is steady ,performance is reliable.
·Able to be matched with dust-removal system.
·It can be made to totally-enclosed type, served with airbrush system, and meets the GMP requirements.
·Easy to clean and to maintain,low cost.
·BY sugar coating machine is used to sugar coating the tablets and pills for pharmaceutical and food industries.
·It can adjust temperature and speed.
♥Technical Parameters♥
Model |
BY-300 |
BY-400 |
BY-600 |
Dia of Coating Pot(mm) |
300 |
400 |
600 |
Speed of Coating Pot(r/min) |
46 |
46 |
36 |
Motor Power(KW) |
0.37 |
0.55 |
0.75 |
Heating Wire Power(W) |
500 |
900 |
1000 |
Blower Power(W) |
40 |
40 |
60 |
Capacity (KG/Time) |
1-2 |
2-5 |
5-15 |
Weight |
60 |
65 |
70 |
Overall Size(mm) |
500*350*700 |
550*400*800 |
800*600*900 |
Externat Heating Power(W) |
500 |
500 |
600 |
Model |
BY-800 |
BY-1000 |
BY-1250 |
Dia of Coating Pot(mm) |
800 |
1000 |
1250 |
Speed of Coating Pot(r/min) |
36 |
32 |
28 |
Motor Power(KW) |
1.1 |
1.1 |
3 |
Heating Wire Power(W) |
1000 |
2000 |
3000 |
Blower Power(W) |
250 |
250 |
250 |
Capacity (KG/Time) |
30-50 |
50-70 |
80-150 |
Weight(KG) |
205 |
220 |
280 |
Overall Size(mm) |
1000*800 *1430mm |
1100*1000 *1560mm |
1250*1200 *1820mm |
Externat Heating Power(W) |
2000 |
2000 |
2000 |
♥Pics Display♥
