Help CenterMetering Pump Filling Machine
Related Products
-
Automatic Ordinary-Pressure Filling Valve Filling MachineNegotiableMOQ: 1 Set -
Automatic Ordinary-Pressure Filling Valve Filling and Capping MachineNegotiableMOQ: 1 Set
-
Automatic Volumetric Plunger-Type Pump Filling and Capping MachineNegotiableMOQ: 1 Set
-
Automatic Centrifugal Pump Filling MachineNegotiableMOQ: 1 Set
-
Semi-automatic Flexible Tube Pump Filling MachineNegotiableMOQ: 1 Set
Specifications
- Suitable for low to middle viscous liquid filling- High Filling Speed
- High Filling Accuracy
Issue | Application Description |
Applicable Filling Materials | Suitable for normal liquids and the liquid which easy to foam while filling. Like kinds of oil. |
Particle Requirement | Applicable for Liquid without particle content |
Typical Filling Material | Liquids like: cooking oil , Lubrication oil and so on |
Best Filling Range | 50ml – 6,000ml |
• Suitable for normal liquids or liquid with low viscosity and the liquid which easy to foam while filling.
• High accuracy assurance for wide range of filling volume.
• Less shut down time by configuration of one filling heads, one pump.
• High speed filling by one pump one frequency convertor.
• Applying backflow filling nozzle to suck-back foams, to avoid foam overflow and drop leakage.
• Assurance of key components’ quality by selecting of International reputable brands
• Program Logic Controller, easy for changing size or modifying parameters and trouble shooting.
No | Components | Material / Short List |
1 | Products Touching Parts | Stainless Steel 304 as the standard, Stainless Steel 316,316L at the Buyer’s option |
2 | Frame Structure/Surface | Stainless Steel 304 |
3 | Programmable Logic Controller | Delta, Siemens, Mitsubishi |
4 | Touch Screen | Weinview, Siemens,Delta,Kinco |
5 | Stepper/Servo Motor | Teco, Delta, Panosonic |
6 | Frequency Convertor | Delta, Schneider |
7 | Electric Components | Schneider,Chint, Ls, Ark |
8 | Protection & Relay | Schneider |
9 | Cylinder, Filter | Airtac , SMC |
10 | Photocell Sensor | Autonics , Keyence, Leuze |
11 | Vacuum Sucker | Airtac, Sunx |
12 | Temperature Controller | Omoron |
Catalogue 1H-xx-x | DG-4 | DG-8 |
Control Method | Automatic | Automatic |
Number of Filling Nozzles | 4 | 8 |
Range of Filling | 50-6000ml | 50-6000ml |
Filling Speed -BPH | 700-960 | 1000-1500 |
Filling Tolerance | <= (+/-)0.2-0.5% subject to the filling range | |
Compress Air Required | 0.6-0.8Mpa | 0.6-0.8Mpa |
Power Requirement | AC 220V/380V 50/60HZ | AC 220V/380V 50/60HZ |
Electricity Consumption | <=2kw | <=2kw |
With shield | Yes | Yes |
With Hopper/Level Control | Yes | Yes |
Following documents are available, but not limited, to be provided upon the stage of purchasing
No | Document | Code | Description |
1 | Products Selection Guide | SG | To select or customize the suitable products for the clients upon the feedback of Selection Guide, which include project background, parameters and other client’s requirement |
2 | Products Profile | PP | To enable the clients understand the overview of the products, Covers sections of Basic Features, Application, Construction, Typical Products, Approvals, and Optional Features |
3 | Installation Instruction | IN | To explain the step of installation of the equipment, and include commissioning instruction as well |
4 | User Manual | UM | To cover the content of Operation & Maintenance and Trouble Shooting |
Customization Philosophy
The product demonstrating may not perfectly meet your requirements, our philosophy is to customize your real need, To minimizing idle capacity and function. To supply you performance and cost balanced products. Following are the factors shall be taken into account during customization:
- Filling Materials
- Container to be filled, type and specification.
- Capacity requirement
- Automation requirement
- Protection requirement
- Other specific requirement
Selection Guide
Selection Guides are available for circulation, contact us to get products selection and customization support.
Statement
- The pictures demonstrating in this profile represent products of range, and subject to the newest or customized design
- Due to the huge number of documentation updating, the data indicated in this profile may not be updated timely, Please contact with our customer service for newest version.
- The features or functions appear in this profile subject to the additional description of quotation
