Specifications
TDP 6 Single punch tablet press with 1 set free round die
tablet press machine ,tablet press , tablet machine
Name: TDP 6 Single punch tablet press with 1 set free round die
Place of Origin: Guangdong China (Mainland) Type: Single Punch Brand Name: OEM Model Number: TDP6
Type: Tablet Pressing Machine Application: Tablet Voltage:: 110V or 220V or 240v or 380v or any Voltage customized
Max.Main Pressure (kn) : 60
Max.Pressure Diameter(mm) : 25
Max.Filling Depth(mm) : 18
Max.Tablet Thickness(mm) : 7.5
Max. Production capacity (p/h) : 3000
Motor (KW) : 1.1
Outside size(mm) : 700X380X695mm
Weight (kg) : 165
The machine is suitable for the industries of Chemical, Foodstuff,Electronic and etc.It is used of pressing medicinal tablets,catalysts,sugar tablets,Calcium tablets,Coffee tablets,Powder Metallurgical,Electronic elements and various tablets of pesticide and fertilizer.etc.in such small-batch production,laboratory and hospital fields.Meanwhile,that machine also can press various abnormity and normal tablet,and press the tablets in two sides with printing as well.
Main Technical Parameters:?
Material: Metal and Aluminum.
Model: TDP-1.5 TDP-5 TDP-6
Max.Main Pressure (kn) 15 50 60
Max.Pressure Diameter(mm) 12 20 25
Max.Filling Depth(mm) 12 16 18
Max.Tablet Thickness(mm) 6 6 7.5
Max. Production capacity (p/h) 4500 4000 3000
Motor (KW) 0.55 0.75 1.1
Outside size(mm) 570×380×630mm 700X380X695mm 700X380X695mm
Weight (kg) 90 120 165
TDP 6 Single punch tablet press with 1 set free round die
