Help CenterAutomatic 5 Liter Cooking Oil Filling Machine for Production Line
Related Products
-
Semi-Automatic Lubrication Grease Hot Filling Machine for Small BusinessNegotiableMOQ: 1 Set -
Semi-Automatic Peanut Butter Hot Filling Machine for Small BusinessNegotiableMOQ: 1 Set
-
Semi-Automatic Tomato Sauce Filling Machine for Small BusinessNegotiableMOQ: 1 Set
-
Semi-Automatic Flammable or Explosive Paste Filling Machine for Small BusinessNegotiableMOQ: 1 Set
-
Semi-Automatic Juice Filling MachineNegotiableMOQ: 1 Set
• Suitable for wide range of viscosity fluids and paste. Even with corrosive characteristic.
• Fully pneumatic controlled type is an ideal fill machine for flammable and explosive liquid or viscosity fluid.
• Easy-adjusting design for filling volume adjustment separately or for all pumps. Large range of adjusting dosage.
• Customized plunger ring selection to adapt different filling materials.
• Equipped with International brands of isolation valves, anti-drop device.
• Assurance of key components’ quality by selecting of International reputable brands
• Various control method of filing for semi-auto type.
Issue |
Application Description |
Applicable Filling Materials |
1) Low to High -Viscosity Fluids |
Particle Requirement |
Applicable for Liquid which consist of small size particle content |
Corrosive Requirement |
Applicable for Liquid which consist of Corrosive and Poisonous content |
Typical Filling Material |
Liquids like: Water , Juice, oil, Medicine, Chemical, etc,especially for varoious kinds of oil. |
Best Filling Range |
10ml – 5000ml |
GZGH Catalogue |
GHALF-5000 |
Special Apply for |
Suitable for the filling of middle-viscous liquids, especially the fluids like oil |
Control Method |
Automatic |
Number of Filling Nozzles |
4 **8,12 Nozzles available for customized** |
Container Moving Type |
Liner |
Ideal Range of Filling-ml |
50-5000 |
Filling Speed –BPM /5000ml |
15 |
Filling Tolerance |
20-1000ml<= (+/-)1%,1000-5000<= (+/-)0.5% |
Compress Air Required |
4-6 bar |
Air Consumption |
15M3/Hour |
Power Requirement |
AC 220V 50/60HZ |
Electricity Consumption |
1.2kw |
Approximate Weight -Net |
1000kg |
With Hopper /level Control |
Yes |
With Pre-Heating |
No |
With Shield |
Yes |
Following documents are available, but not limited, to be provided upon the stage of purchasing
No |
Document |
Code |
Description |
1 |
Products Selection Guide |
SG |
To select or customize the suitable products for the clients upon the feedback of Selection Guide, which include project background, parameters and other client’s requirement |
2 |
Products Profile |
PP |
To enable the clients understand the overview of the products, Covers sections of Basic Features, Application, Construction, Typical Products, Approvals, and Optional Features |
3 |
Installation Instruction |
IN |
To explain the step of installation of the equipment, and include commissioning instruction as well |
4 |
User Manual |
UM |
To cover the content of Operation & Maintenance and Trouble Shooting |
CE Approval
Customization Philosophy
Our philosophy is to customize your real need, No idle capacity and function. To supply you performance and cost balanced products. Following are the factors shall be taken into account during customization:
a) Filling Materials
b) Container to be filled, type and specification.
c) Capacity requirement
d) Automation requirement
e) Protection requirement
f) Other specific requirement
Selection Guide
Selection Guides are available for circulation, contact us to get products selection support.
