ce Skid Steer Loader XSCM 3.5 Tons Mini Skid Steer Loader ST938
US$ 9,000 - 60,500
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
XSCM
Model Number:
ST938
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB China port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
XSCM 1t Wheel Loader CE 4wd Mini Wheel Loader ZL-10 for SaleUS$ 9,000 - 12,800MOQ: 1 Set -
XSCM Zl30g Road Construction Equipment With ceUS$ 9,000 - 60,500MOQ: 1 Set
-
XSCM Mini Loader ZL15F CE Certification Small Construction EquipmentUS$ 12,300 - 13,800MOQ: 1 Set
-
XSCM ST935 ce Mini Front End Loader for SaleUS$ 9,000 - 60,500MOQ: 1 Set
-
XSCM ST956 5t Mini Track Loader for SaleUS$ 9,000 - 20,500MOQ: 1 Set
Condition
New
Brand Name
XSCM
Model Number
ST938
Place of Origin
Fujian, China
Type
Skid Steer Loader
Moving Type
Wheel Loader
Dimension(Long * Breadth * High)
7100*2510*3170mm
Rated Load
3.5t
Certification
CE
Warranty
1year
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
3.5 tons mini skid steer loader ST938 adopt top grade shockthe skid steer loader with comfortable chairs
XSCM 3.5tons mini skid steer loader ST938 Standard equipment control hydraulic system, reduce the labor intensity of operators furthest
the mini skid steer loader use Deutz TD226B-6D1 engine high power and torque reserve low fuel consumption and noise high reliability
3.5tons mini skid steer loader enforced driving axle is higher in loading power and reliability
ce skid steer loader XSCM 3.5 tons mini skid steer loader ST938 main specifications as following:
| Overall working weight | 10700kg | |
| Rated bucket capacity | 2.0m³ | |
| Rated load | 3.5t | |
| Max. traction force | 105kN | |
| Max. breakout force | 96kN | |
| Max. grade ability | 30° | |
| Dumping height | 2950mm | |
| Dumping reach | 1050mm | |
| Engine Model | Deutz TD226B-6D1 | |
| engine Rated power | kw | 105 |
| Min. specific fuel consumption | g/kw.h | 231 |
| Max. speed | km/h | 38 |
| Mining steering radius | mm | Outside bucket:5912, outside rear wheel:5381 |
| system working pressure | Mpa | 16 |
| Boom lifting time | s | 5.3 |
| Total time | s | 9.2 |
| Service brake | air over hydraulic disc brake | |
| Parking brake | Cable-controlled caliper disc brake | |
| Inter-bore of cylinder/stroke | mm | 6- 105×120 |
