XSCM Mini Loader ZL15F CE Certification Small Construction Equipment
US$ 12,300 - 13,800
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Brand Name:
XSCM
Model Number:
zl15
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB China port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
XSCM ST935 ce Mini Front End Loader for SaleUS$ 9,000 - 60,500MOQ: 1 Set -
XSCM ST956 5t Mini Track Loader for SaleUS$ 9,000 - 20,500MOQ: 1 Set
-
XSCM ce 4wd Zl-16 Mini Wheel Loader for SaleUS$ 9,000 - 60,500MOQ: 1 Set
-
XSCM ce 4wd 1.2t Mini Front LoaderUS$ 9,000 - 10,600MOQ: 1 Set
-
2013 Hot Bona Small Wheel Loader XSCM ST920-II for SaleUS$ 9,500 - 20,500MOQ: 1 Set
Condition
New
Brand Name
XSCM
Model Number
zl15
Place of Origin
Fujian, China
Type
Mini Loader
Moving Type
Wheel Loader
Dimension(Long * Breadth * High)
4870*1750*2650mm
Rated Load
1500kg
Certification
CE
Warranty
1 year
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
small construction equipment mini loader zl15F0.8CBM bucket
flexible operation
good visibility
high efficiency
small construction equipment mini loader zl15F features
XINCHAI 498T(EURO Ⅲ) Engine(37kw)
0.8m³ bucket
1500kg of rated load
2580mm of dumping height
mini loader ZL15F CE certification small construction equipment detail specification
| Rated load | 1500kg |
| Rated bucket capacity | 0.8m3 |
| Bucket width | 1750mm |
| Track base | 1400mm |
| Wheel base | 1950mm |
| Min. turning radius | 4400mm |
| Min. ground clearance | 270mm |
| Max. dumping height | 2580mm |
| Dumping reach | 860mm |
| Lifting time | 4s |
| Hydraulic cycle time | 9s |
| Max. tilt angle | 30° |
| Breakout force | 42KN |
| Driving mode | Four-wheel drive |
| Operating weight | 3500kg |
| Dimension(L*W*H) | 4870*1750*2650mm |
| Engine model | XINCHAI 498T(EURO Ⅲ) |
| Engine type | In-line arrangement, water cooled,four-cycle diesel engine |
| Start mode | Electric |
| Rated power | 36.8KW |
| Rated speeds | 2200rpm |
| Gear shift | Forward 2/reverse 2 |
| Brake mode | Four-wheel hydraulic spread-shoed brake |
| Tyre size | 12-16.5 |
