SHINEEAST SPT80 Impulse Test Bench

Specifications

Impulse Test Machine
ISO9001
Human-machine interactive dialog operation
Medium:Hydraulic oil
Max. pulse pressure:80Mpa

Impulse Test Benches include SPT80 Model are specialized test rigs to provide  pressure,impulse as well as deflection and vibration etc. functional testing for various hydraulic hoses,automobile and aeronautic components.They are powered by hydraulic pump motor and use Shineeast hydraulic pump for oil pressurization.Pulse pressure up to maximally 80Mpa.Test medium of Hydraulic oil ISO VG46 or ISO VG32.



Applications

• Impulse tests of hydraulic hose lines using in construction machinery, mining machinery,aeronautic hoses, valves,vessels and automobile pumpbrake system or components,power steering etc
• Deflection, vibration and etc. functional testings available



Key features and advantages

• Separate testing and driven system. Available for easily temperature control as well as powering a variety of mediums,such as oil,water or non-corrosive liquids
• Control units with IPC and PLC
• Real-time monitoring as well as data recorded on high-speed sampling cards and also curves printing
• Alarming at due time bursting and due point recording
• A variety of tooling fixtures meeting with different mounting method requirements
• Non-welded pipeline system
• Industrial control configuration software or on LABVIEW
• Deflection and vibration functional testing for option



Technical parameters

Type	SPT80
Max. pulse pressure	80Mpa
Test medium	Hydraulic oil ISO VG46 or ISO VG32
Test medium temperature range	Room temperature to 120 degrees centigrade
Enviroment temperature	Room temperature
Pressure source	Shineeast hydraulic oil pump
Power source	Hydraulic pump motor
Energy demand(Power supply)	45KW
Control unit	PC and PLC
Pulse frequency	0-1.25Hz
Deflection frequency	0.5-1.0Hz
Vibration frequency	10-50Hz
Dimensions of the test chamber (width x depth x height) approx.	2350×1600×1850mm
