SHINEEAST GD 64 Air Operated Pump

Specifications

• GD series air driven liquid pumps are high pressure reciprocating plunger pumps of double acting,single air drive head model. Air drive pressure from 3bar(43.5 psi) to 8bar(116 psi) maximum.
• They are characterized by the same features as the G series pumps with single acting, single air drive head , but they have less pulsations and deliver approx. 50 % more flow.Provided for operating pressures up to3,200 bar(46,400 psi).The same with G series,they are suitable for application with high pressure requirements.

Key features

• One model available in 12 ratios
• Double acting for efficiency operation
• Compatibility with a variety of liquids
• Aluminum bodies and wetted materials of carbon steel or stainless steel
• High quality seals, long service life available
• Rustproof and beautiful generous in blue colors with oxidation treatment applying to the aluminum components
• Robust, reliable, compact and easy to maintain proven design
• No need for air line lubrication
• Wide range of pressure ratios to meeting with different requirements
• GD Series pumps come standard with side inlet

Technical parameters

Note:All data based on air drive pressure of 6 bar.* at drive air of 8 bar.

Please consult us for printable dimensional drawings and performance charts for GD series pumps sized to your specific application parameters.
