Manufacture JAC Car Carrier Flat Board Wrecker

US$ 15,000 - 23,000 MOQ: 1 Set

Key Specifications

Fuel Type:

Diesel

Emission Standard:

Euro 3

Condition:

New

Hubei Jiangnan Special Automobile Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

any port in China

Delivery Detail:

Delivery time depends on order quantity.

Fuel Type Diesel

Emission Standard Euro 3

Condition New

Transmission Type Manual

Dimensions (L x W x H) (mm) 7150*2320*2420

Place of Origin Hubei, China

Brand Name JAC

Model Number JDF5060TQZJAC

JAC Flat board type tow truck

Basic Information
Vehicle name	Tow Truck		Chassis:		HFC1061K93
Outline size(L×W×H) (mm)	715023202420		Cargo inline size(L×W×H)(mm):		/
Rating mass(kg)	/		Empty mass(Kg):		4800
Full mass(kg)	6125		Emission standard		Euro 3
Engine Information
Model	YZ4DB1-30		Type	6 Cylinder Diesel engine
Power/displacement(KW/ML)	95(129HP)/4087		Manufacture	Yangzhou
Chassis Information
Wheelbase(mm):	3815		Axle load(kg) F/R			2350/3775
Tire	7.50-16 10PR,8.25-16 8PR,7.50R16 10PR		Max speed (km/h):			95
Front overhang(mm)	1085		Rear overhang(mm)			1910
Front track(mm)	1665		Rear track(mm)			1525
Approach angel(°)	23		Departure angle(°)			14
Steering	Power steering		Brake			Air brake
Cabin	3
Special function
*Flat length x width(mm): 53302330**		Effective length(mm): 1300
Flat Stroke(mm): 2680		Rated lifting quality(kg):1140
Flat maximum bearing quality(kg):3000		The rated supporting lead quality(kg):6125
Rated traction winch(kg): 4000		The length of wire rope(m): 25
Trade terms
Quote Lifetime	30days (we promise the quote is effective in the lifetime!)
Payment terms	1. 30% by T/T in advance, 70% by T/T against the copy of Bill-of-Lading. 2. Letter of credit payment for some countries and regions.
Deliver time	30workdays
MOQ	1set
Supply quantity	3,000sets/month
Package	waxing
