Help CenterTactile Membrane Panel With Aluminum Carrier
Related Products
-
Push Button Membrane Panel Good QualityUS$ 1 - 10MOQ: 500 Pieces -
Tactile NameplatesUS$ 1 - 10MOQ: 500 Pieces
-
Poly Domes Tactile Membrane Switch Backlit Branding In Home Apliance And EquipmentUS$ 1 - 3MOQ: 500 Pieces
-
Poly Domes Tactile Membrane Switch Backlit In Home Apliance And EquipmentUS$ 1 - 3MOQ: 500 Pieces
-
Tactile Membrane Switch Backlit Branding In Home Apliance And EquipmentUS$ 1 - 3MOQ: 500 Pieces
Specifications
Tactile Membrane Panel With Aluminum Carrier2.PET/PVC&3M adhesive
3.shiny/matt/frosting finish
4.100% QC
5.OEM&ODM welcome
Title: Screen Printed and Die-cut, Self Adhesive Membrane Control Panel With Colorful Transparent Window, Touch Screen Overlay, Self Adhesive Overlays With Punched Window
Welcome customers to inquiry on your specification, we would be very pleased to help you find what you need.
Tactile Membrane Panel With Aluminum Carrier
custom graphic overlay Performance Index | |
1.Electronic characteristics | |
Circuit rating |
35V (DC), 100mA, 1W |
Contact resistance |
10Ω~500Ω (According the trace length and materials) |
Insulation resistance |
> 100MΩ 250V DC |
Contact bounce |
≤ 5ms |
Dielectric withstand |
250VRms (50~60Hz 1min) |
Life expectancy |
flat type ≥ 5 million times, tactile type ≥ 1 million times |
2.Mechanical Properties | |
Actuation force |
flat type: 57-284g (2-10 Oz), tactile type: 170~397g (6~14 Oz) |
Switch stroke |
flat type: 0.1~0.5mm, tactile type: 0.6~1.5mm |
3.Environmental parameters | |
Operating Temperature |
-40°C~+80°C |
Storage temperature |
-40°C~+85°C |
Humidity |
40°C, 90% ~95%, 240 hours |
Shenzhen Lunfeng Technology Co., Ltd
- 15years of manufacture experience in Shenzhen, China
- Specialize in membrane switch, membrane keypad, membrane keyboard, graphic overlay, touch screen, nameplate…
- Passed ISO9001:2008
- Over 600 stable customers at home and abroad
Custom-made membrane switch panel /membrane keypad Main Application:
Home appliances: washing machine, induction, microwave oven, remote control etc.
Industrial equipment: CNC lathe, injection molding machine etc.
Commercial equipment: cash register, electronic scale, refueling machine, medical equipment. Measuring instruments, telecommunication equipment, OA equipment, Information application productstoys…etc.
Notes:
All trademarks shown here are for reference purposes only. They are the property of their respective owners and we are not authorized to sell items bearing such trademarks.
Please feel free to contact us for any queries!
