Help CenterPET PC PVC Newest Type Membrane Switch Panel 2011
Related Products
-
Tactile Membrane Panel With Aluminum CarrierUS$ 1 - 10MOQ: 500 Pieces -
Push Button Membrane Panel Good QualityUS$ 1 - 10MOQ: 500 Pieces
-
Tactile NameplatesUS$ 1 - 10MOQ: 500 Pieces
-
Poly Domes Tactile Membrane Switch Backlit Branding In Home Apliance And EquipmentUS$ 1 - 3MOQ: 500 Pieces
-
Poly Domes Tactile Membrane Switch Backlit In Home Apliance And EquipmentUS$ 1 - 3MOQ: 500 Pieces
Specifications
Membrane switches panel1 PET,PC,PVC
2 rear adhesive 3M468/467
3 Type metal dome tactile
4 pass SGS roh
PET PC PVC Newest Type Membrane Switch Panel 2011
Tactile membrane switch panel embossed LED and metal domes advantages:
1. Beautiful appearance, bright in color, various types of products can be designed according to customer requirements.
2. Small size, light weight, thin thickness, good tactility, abrasion resistant, Installation and connection convenience.
3. Tightness is good, moisture-proof, dust-proof, anti-oil, anti-corrosion and erosion of harmful gases proof, acid and alkali proof, quake proof.
4. Low cost, high lifespan. The life expectancy of different types of membrane switch is more than 1 million times.
5. Easy to operate, intuitive, safe and reliable, in-house 100% functionally tested.
At Lunfeng Factory
We provide superior quality membrane switches in a wide variety of
formats. In addition, we offer design engineering to ensure that
your membrane switches, front panels and graphic overlays
deliver excellence in function, durability and design.
Specifications
Membrane switch Specifications/Special Features | |
Material |
matte PC (smooth), gloss PC + matte oil, gloss PC, PET, and PVC |
Dimension |
according the request |
Thickness |
0.05mm~1.0mm |
Packing |
Individual package |
Features |
1) Embossed keys: no embossed keys and domes, domes without embossed keys, embossed keys without domes, embossed keys and domes |
2) Screen printing | |
3) 3M rear adhesive:3M9448,3M9080,3M467,3M468, 3M300LSE, 3M9671 etc. | |
4) Die cut to any shape | |
|
5) With clear or punched windows LED windows: transparent, translucent, matte | |
|
6) Tail: tail with clear mask or green mask Small MOQ depending on customer’s request, can be negotiated | |
|
Higher quality,competitive price and satisfactory service!
| |
Specialize in manufactuing membrane switch:
• Overlay+circuit+LED+metal dome or poly dome array+connector+double side tape
• EL backlight+Rubber keys
• Aluminum plate+Rubber keys
• Metal domes
• Flat without Tactile Effect
• Embossing with Tactile Effect
• Embossing with Metal Dome
• Membrane Switch with FPC
Performance indicators:
1. Electronic characteristics
• Circuit rating: 35V (DC), 100mA, 1W
• Contact resistance: 10Ω--500Ω (According the trace length and materials to comfirm)
• Insulation resistance:> 100MΩ 250V DC
• Contact bounce: ≤ 5ms
• Dielectric withstand:250VRms (50-60Hz 1min)
• Life expectancy: flat type ≥ 5 million times
• tactile type: ≥ 1 million times
2. Mechanical Properties Actuation force
• flat type 57-284g (2-10 Oz)
• tactile type 170-397g (6-14 Oz)
• Switch stroke: flat type 0.1-0.5mm
• tactile type 0.6-1.5mm
3. Environmental parameters
• Operating Temperature: -40 C- +80 C
• Storage temperature: -40 C - +85 C
• Humidity: 40C , 90% -95%, 240 hours
Custom-made membrane switch/membrane keypad Main Application:
Home appliances: washing machine, induction, microwave oven, remote control etc.
Industrial equipment: CNC lathe, injection molding machine etc.
Commercial equipment: cash register, electronic scale, refueling machine, medical equipment. Measuring instruments, telecommunication equipment, OA equipment, Information application productstoys…etc.
Notes:
All product, pictures and trademarks and shown here are for reference purposes only. They are property of their respective owners and we are not authorized to sell items bearing such trademarks.
Please feel free to contact us for any queries!
Picutures show
