China Uniaxial Geogrid Lattice
- 120000 Square Meter / Square Meters per Month
- QingDao
- T/T Credit Card PayPal
- TGGS75-400HDPE Plastic Geogrid Room Large Government Project River Maintenance and Reinforcement
- TGGS75-400HDPE Plastic Geogrid Room Large Government Project Parking Lot Roadbed Reinforcement
- TGGS75-400HDPE Plastic Geogrid Room Large Government Project Roadbed Laying and Reinforcement
- 1500g plastic geotextile mat mesh interwoven drainage board
- TGGS75-400 geocell perforated honeycomb geocell hybrid retaining wall
- TGGS100-400 perforated honeycomb geogrid mixed retaining wall for stabilizing highway subgrade
Product Details
Place of Origin: | Shandong, China | Brand Name: | RH | Model Number: | RHUX-uniaxial plastic geogrid |
Material: | Plastic |
Product Description
Uniaxial Plastic Geogrid Specifications
China Uniaxial Geogrid Lattice
Item Model | TGDG25 | TGDG35 | TGDG50 | TGDG80 | TGDG120 | TGDG160 | TGDG200 | |
Width(m) | 1.0~3.0 |
| ||||||
Yield strength ≥KN/M | HDPE | 25 | 35 | 50 | 80 | 120 | 160 |
|
PP | 25 | 35 | 50 | 80 | 120 | 160 | 200 | |
Strength at 2% elongation ≥KN/M | HDPE | 6 | 7.5 | 12 | 21 | 33 | 47 |
|
PP | 7 | 10 | 12 | 26 | 36 | 45 | 56 | |
Strength at 5% elongation ≥KN/M | HDPE | 12 | 21.5 | 23 | 40 | 65 | 93 |
|
PP | 14 | 22 | 28 | 48 | 72 | 90 | 112 | |
Elongation %<= | HDPE | 11.5 |
| |||||
PP | 10 |
| ||||||
Length per roll(m) | 50,100 |
|
Uniaxial Plastic Geogrid Introduction:
Uniaxial plastic geogrid is made of high polyer, which is extruded the thin sheet ,then rushed the regular mesh and longitudinal extension. This process makes polymer into directional linear state and formation of distributed homogeneously, joint intensity high oblong reticular holistic structure. This structure has quite high tensile strength and tensile modulus, especially our company has more excellent tensile strength and tensile modulus than the international level(elongation at 2%~5%). It can provide the ideal force bear and spread of the interlock systems for the soil. This product has a high tensile strength(>150Mpa),and it's suitable for all kinds of soil and widely useful for stiffened reinforcement material at present.
Uniaxial Plastic Geogrid Applications & Function
Uniaxial geogrids are compositional materials for civil engineering with high intensity which be widely used for embankment, tunnels, docks, roads, railways and other constructional fields and their main usages are as follows.
a. Consolidate road foundations and distribute the load effectively. By these means, the road foundations may have a better stability, endurance and a longer life.
b. Help road foundations to bear protean heavy loads.
c. Avoid granular base loss and cracking.
d. Enhance self-load of filled soil behind the slopes and distribute the pressure of slopes as well as reduce the cost of construction and maintenance but increase its lifespan.
e. Servicing slopes by fusing concrete allow to save investment by 30 percent to 50 percent as well as to shorten the period at least by 50 percent compared to tradition un-reinforced ones.
f. Asphalt road take advantage of these products can reduce rut and reflective cracking by 3 to 9 times as well as structural thickness of up to 36 percent.
g. Be use in all kinds of soil without getting distant material, which can greatly shorten construction lifespan.
h. Greatly reduce the cost of construction with its simple and rapid characteristics.
Our Other Products
If you want to learn more about our products,please click here.
What We Can Do For You
China Uniaxial Geogrid Lattice
1. We have our own factory. We can provide what you want in competitive price.
2. Our company provides before-sales, in-sales and after-sales services with heart and soul in engineering construction and products selection.
3. Our company is in strict accordance with national standards and related standards. Our company passed ISO9001 and BV quality system authentication.
4.We have been exporting for 5 years.
We can provide necessary certificates to make customs clearance easier for you.
We know well about container. We can make advice for you to reduce freight without damaging goods.
5.We can provide Certificate of Origin. For Southeast Asia, FORM E and FORM A. For Chile, FORM F. For Africa, C O.
We are looking forward to your sincere cooperation. If you have any question, please feel free to contact us.
