Specifications
rrosion resistence,long life2.fast and convenient construction
3.,short engineering cycle ,low cost
4.high strength
Properties:
Steel plastic geogrid is steel wire through the high density polyethylene wrapped into high strength the strips, welded by ultrasound, and according to the needs of the project to use different diameter and the number of steel to change with pulling force size. Through the production process to the plastic surface processing, compressed into concave and convex decorative pattern, increased the welding some strength, improve muscle with surface friction coefficient, the role of resistance to grill has resistance from the level of the packing shear, improve the bearing capacity of soft foundation soil impedance failure surface to form, meet the engineering permanent engineering requirements.
Application
1:Tensile strength, high creep degeneration small, it has good flexibility, low elongation at break, and effectively solved the engineering distortion and quite a shift, adapt to the environment soil, and can meet the retaining wall of high grade highway tall role.
2:Effectively improve the bearing the reinforcement embedded locks, bite role, great enhancement the bearing capacity of the foundation, effective constraint of soil lateral displacement, enhance the foundation stable performance.
3: Compared with the traditional grille has more strength, high bearing capacity is strong, prevent ageing, friction coefficient.
4: Effectively avoid in construction process by a few words of rolling, damage caused by the construction damage.
5: Widely used in railway, highway, the dam.The bank of the river, slope protection, enhance bridge road surface treatment etc.
Biaxial steelplastic sticking-weldig geogrid
| Specifications | 30-30 | 40-40 | 50-50 | 60-60 | 80-80 | 100-100 | 150-150 |
| Tensile Strength KN/m(LD) | ≥30 | ≥40 | ≥50 | ≥60 | ≥80 | ≥100 | ≥150 |
| Tensile Strength KN/m(TD) | ≥30 | ≥40 | ≥50 | ≥60 | ≥80 | ≥100 | ≥150 |
| Elongation Rate(LD TD) | ≤2 | ≤2 | ≤2 | ≤2 | ≤2 | ≤2 | ≤2 |
| Tensile Strength at 1% Elongation Rate(LD) | ≥20 | ≥32 | ≥40 | ≥48 | ≥63 | ≥81 | ≥125 |
| Tensile Strength at 1% Elongation Rate(TD) | ≥20 | ≥32 | ≥40 | ≥48 | ≥63 | ≥81 | ≥125 |
| Limit PeelForce at Welded Bonded Point N | ≥100 | ≥100 | ≥100 | ≥100 | ≥100 | ≥100 | ≥100 |
| Products in the range of coal mine | Fire out time from outer flam | ≤3 | |||||
| Surface resistivity | <1×109 | ||||||
