Specifications
1.Available size:3"-15"2.High_resolution
3.High speed response
4.High stability and never drift
Transmittance>92% the highest can reach to 100% Touch resolution 4096x 4096 Touch speed of scan :30scans/s
The smallest touchbody>4mm the speed of react<16ms durability>more than 60,000,000 times single point touch adaptive capacity
The smooth surface steel ball with anti-detonating quality diameter is 65.5mm fall down from 1 meter freely., the samples keep the same
Electric parts: work voltage : DC 5V ,+/-5% without noise
Suit for the windows2000/xp/2003/CE/Linux operation system
Communication way:USB or RS-232
Altitude : 3,000 meters Full angles anti light anti heavy lighting waterproof IP 65
Wont change with the environment
4 wire General information | |
Available size | 3”-11” |
Touch Activation Force | 20-150 g |
Thickness | ITO film:0.188mm |
Operating voltage | Less than 12v |
Operating current | DC 50ma/5V |
X,Y resistance | According to the size |
Insulation resistance | ≥20MΩ/25V(DC) |
Linearity | ≤1.5% |
Response Time | <10ms |
Transparency: | ≥75% |
Surface Disposal | Anti Glare, Glare |
Operating Temperature | -20°C~+70°C,≤70%RH,noncondensing |
Storage Temperature | -30°C~+80°C,≤90%RH,noncondensing |
Humidity | <95% |
Surface Hardness | 3H |
Pen Hitting Life | 1millions times |
Pen Sliding Durability | 100thousand times |
