China Supplier Stainless steel,iron,Aluminum,copper chinese machines laser yag marking machine
chinese machines laser yag marking machin Performance Features
- Red light pointer realizes the exact positioning with focus indication. Equipped with luxury component, imported focus lens and reflected mirror, USA imported diode module, top glass scanning head, famous English “Gooch” brand Q switch, makes high efficiency and steady performance.
- Perfect Laser’sMetal Diode Laser Marking Machine no need to change the consumables (such as laser lamp), free of maintenance,very low operation cost.
- Perfect Laser’s marking software is particularly designed & written for laser marking, has multifunction and friendly interface, easy to operate, can achieve different marking parameters setting and application, support 2D coding, can support any computer operation system and all kinds of languages.
- With 17’ LCD screen & industry computer system, 1G memory, 80G hard disk, can ensure the machine to work with high efficiency.High efficient water cooling, uses special auto emergency water stop protection function, can ensure the machine to work under any environment steadily.
.
chinese machines laser yag marking machinTechinical Date:
Machine Type |
Metal chinese machines laser yag marking machinMachine |
||||||
Laser Marking Machine |
PEDB-300 |
PEDB-300 |
PEDB-300 |
PEDB-300E |
PEDB-350 |
||
Laser Output Power |
50W |
75W |
100W |
50W |
12W |
||
Pump Type |
Diode Side-pump |
Diode End-Pump |
|||||
Laser Wavelength |
1064nm |
||||||
Standard Marking Area |
110 mm*110mm |
||||||
Optional Marking Area |
70mm*70mm/175 mm*175mm |
||||||
Beam Quality M2 |
<3 (@ 25A) |
||||||
Marking Depth |
0.01~0.2mm |
||||||
Marking Speed |
7000mm/s |
||||||
Repeated accuracy |
±0.01mm |
||||||
Minimum character |
0.1mm |
||||||
Minimum line width |
0.015mm |
||||||
Electric power requirement |
380V/50Hz Or 220V/50-60Hz |
||||||
Machine power |
3KW |
||||||
|
Dimensions (L*W*H) |
Mainframe |
240mm*1280mm*1200mm |
|||||
Controlling Cabinet |
590mm*560mm*800mm |
||||||
Water-cooling Machine |
540mm*700mm*900mm |
||||||
chinese machines laser yag marking machinApplication:
Perfect Laser’s Metal chinese machines laser yag marking machinMachine is widely for stainless steel marking, carbon steel marking, iron marking, aluminum marking, copper marking, brass marking, anodized and coated materials marking, etc., and non-metallic such as nylon marking, ABS/PVC/PC board marking, hard plastics marking, rubber marking, resin marking, ceramic marking etc. in the industries of electronic and communication products, IC products, electric lines, cable computer components and electric appliance, every kind of precision parts, hardware tools, instrument appliance, aviation and spaceflight appliance, jewelry, garments, instruments, gifts, office devices, brand scutcheon, sanitary ware appliance, dishware, food, drinking, smoking and alcohol,etc.
After- sales service for fiber laser marking machine:
We have 2 years guarantee for the machine .
We will enclose an " English Instruction Book", "English Operation Manual" and "Training Video" (in English version) to you, which is easily understood and handle by the customer.
Terms&Conditions:
1.Payment method: T/T in advance,Alibaba Escrow,PayPal,L/C.
2.Price Validity: 1 month
3.Production lead time :7-10 working days.
4.Delivery Method: Compound wooden cases by sea (please indicate the destination port).
5.Guarantee of Quality and After Sales-Service:
The guarantee period of quality shall be 24 months counting from the date on which the commodity arrives at the port of destination.
Machine in our clients workshop
Laser machines in our workshop
Marking Machine Samples:
Certification:
EXhibition:
Customer VIsit Photographs:
Pls don't hesitate to send us enquiry if you have interest with our machines!! :)
Video, Machine Photo,Samples, if you need , pls send me inquiry!
