Specifications
1. Model: JY series2. Rated Voltage: 220V
3. Rated frequency: 50HZ, 60HZ
4. electric motor with competitive price
JY series single-phase capacitor-start induction motor
1. Model: JY series
2. Rated Voltage: 220V
3. Rated frequency: 50HZ, 60HZ
4. electric motor with competitive price
Advantages:
JY series single-phase capacitor start induction motor is widely used in air compressors, refrigerators, medical apparatus and other small machineswhich demand full-load starting, a large starting torque and limited starting current.
These series motors are of totally enclosed fan-cooled, and have three frame sizes, 09, 1,2. The frames are made of cast iron or cast aluminium according to the requests.
Operating conditions:
1. Ambient temperature: -15°C<q<40°C
2.Altitude: Not exceeding 1000 meters
3.Rated voltage: 220V
4.Rated frequency: 50HZ/60HZ
5.Duty/Rating: Continuous ( SI )
6.Insulation class: Class B
7.Protection: IP44
8. Cooling method: IC0141
FUAN LIYUAN ELECTRICAL MACHINERY CO.LTD, professionally produces the motor, generator, water pump of different series, which have been sold to all the China and exported to more than 100 countries in America, Europe, Southeast Asia and so on, with the high quality and best prices, the products are warmly welcome by the clients from the home and abroad. The main products are as follows: Y, Y2, AEEF, Series three phase induction motor. YC, JY series heavy-duty single-phase induction motor. MY, MG, ML, MS series induction motor with the aluminum housings. YCG series induction motor with the steel-plate housings. ST, STC series generator , TZH series Compound Excitation generator. SFS, GFS series low noise diesel generating set. LY950...LY6500 series gasoline generator, and IDB, QB, JET... Series water pump .
