Specifications
1. Model: Y series2. Power: AC motor
3. Rated frequency: 50HZ, 60HZ
4. electric motor with competitive price
Y series three-phase induction motor
1. Model: Y series
2. Power: AC motor
3. Rated frequency: 50HZ, 60HZ
4. electric motor with competitive price
Advantages:
1. Y series motor are totally enclosed fan cooled (TEFC), three-phase squirrel cage induction motors, it is national uniform design in conformity with the relevant standards of IEC34-1 and JB/T9616-1999, enjoys international interchangeable features.
2. Y series motors have outstanding performance such as high efficiency, engry saving, high starting torque, low noise, slight vibration, reliable operation and easy maintenance, etc.
3. Y series motors are widely used in many places, where do not exsit combustible, explosive or corrosive gas, and special equipments, such as machine tools, pumps, blowers, transport machinery, mixer, agriculture machinery and food machines, etc.
Operating conditions:
- Ambient temperature: -15°C<q<40°C
- Rated voltage: 380V or any voltage between 220-760V
- Rated frequency: 50HZ, 60HZ
- Protection class: IP44, IP54, IP55.
- Insulation class: B, F, H.
- Altitude: not exceeding 1000m.
- Cooling method: IC0141 Duty: SI (continuous)
- Connection: Star-connection for up to 3kw, delta-connection for 4kw and above.
FUAN LIYUAN ELECTRICAL MACHINERY CO.LTD, professionally produces the motor, generator, water pump of different series, which have been sold to all the China and exported to more than 100 countries in America, Europe, Southeast Asia and so on, with the high quality and best prices, the products are warmly welcome by the clients from the home and abroad. The main products are as follows: Y, Y2, AEEF, Series three phase induction motor. YC, JY series heavy-duty single-phase induction motor. MY, MG, ML, MS series induction motor with the aluminum housings. YCG series induction motor with the steel-plate housings. ST, STC series generator , TZH series Compound Excitation generator. SFS, GFS series low noise diesel generating set. LY950...LY6500 series gasoline generator, and IDB, QB, JET... Series water pump .
