Home > Products > Push Button Switch > GB7-BG21 CNGAD GB7 Series 2-position 1 NO Key Switch
GB7-BG21 CNGAD GB7 Series 2-position 1 NO Key Switch
US$ 0.55 - 2
/ Piece
100 Pieces(Min. Order)
- NINGBO/SHANGHAI
- T/T
You May Like
-
GB5-AG21 CNGAD GB5 Series Black 2-position 1NO Key Switch
-
GB7-BCW31 CNGAD GB7 Series Black/red/green Mushroom Button Switch
-
GB7-BD21CNGAD GB7 Series Black 2-position Switch Button
-
GB7-BS542 CNGAD GB7 Series Red Mushroom Button Switch
-
GB7-BW42 CNGAD GB7 Series Red Push With Lamp Button Switch
-
GB7-BA31 CNGAD GB7 Momentary Green 1NO Button Switch
Product Details
| Place of Origin | Zhejiang, China | Brand Name | CNGAD | |
| Model Number | GB7-BG21 | Protection Level | IP65 | |
| Max. Current | 10A | Max. Voltage | 220V |
Product Description
GB7-BG21 CNGAD GB7 series 2-position 1 NO key switch
Application and main technical parameters
1) Operational Voltage: No exceed than 380AC or no exceed than 220DC
2) Operational temperation: -25 to +70
3)Operational humidity: 45% to 90%
4) power-frequency withstand voltage: 2500V AC, 1min
5) contact resistance: ≤ 50mΩ
6) Mechanical durability: Monentary 1000, 000, maintained 250, 000
7)Electrical durability: 500, 000
8) Protection grade: IP65, IP67 with cover
9)Certificate: CCC, CE
