100% Copper Winding Stc Alternator With Cheapest Price

100% Copper Winding Stc Alternator With Cheapest Price photo-1
100% Copper Winding Stc Alternator With Cheapest Price photo-2
100% Copper Winding Stc Alternator With Cheapest Price photo-3
100% Copper Winding Stc Alternator With Cheapest Price photo-4
100% Copper Winding Stc Alternator With Cheapest Price photo-5
100% Copper Winding Stc Alternator With Cheapest Price photo-6
US$ 50 - 700 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
OEM
Model Number:
STC
Payment & Shipping
Payment Methods:
Port of Shipment:
FUZHOU
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Fujian, China
Brand Name OEM
Model Number STC
100% copper winding stc alternator with cheapest  price

1.brush alternator
2.class B.IP44,4poles
uld be fit on each engine
4.output:2-50kw


Technical Date

Model Output (kW) Voltage(V) Current (A) Power factor Speed Pole number
KVA kW (cos) (r.p.m)
STC-3 3.8 3 400 5.4 0.8 1500 4
STC-5 6.3 5 400 9 0.8 1500 4
STC-7.5 9.4 7.5 400 13.5 0.8 1500 4
STC-8 10 8 400 14.4 0.8 1500 4
STC-10 12.5 10 400 18.1 0.8 1500 4
STC-12 15 12 400 21.7 0.8 1500 4
STC-15 18.8 15 400 27.1 0.8 1500 4
STC-20 25 20 400 36.1 0.8 1500 4
STC-24 30 24 400 43.3 0.8 1500 4
STC-30 37.5 30 400 54.1 0.8 1500 4
STC-40 50 40 400 72.2 0.8 1500 4
STC-50 62.5 50 400 90.2 0.8 1500 4

ST series  generators are widely used in town,countryside,worksites,mountain and pasture districts as electric power source for lighting purpose,they can also be used as reserved power source for emergency.
The series generators are of drip-poof with rotary field type and adopt harmonic excitation system,easy operation and maintenance.
The generators are ther-phase,four-wire type,adopted star connection with neutral point,The rated line voltage is 400V,phase voltage 230V,frequency 50Hz,power factor 0.8(lag).we can provide 60Hz and other voltage generators according to the customer's request.

They can be coupled with a prime mover directly or through V-belt making right or revese continuous rotation at the rated speed when the revolution slip of prime mover is 3% and load varies within the range of 0100%cosX=0.81.0 they give good constunr voltage.
The generators offer consranr voltage when sudden change(increase or decrease) of load,the generator will soon return to their normal working state in the same time,the generator can directly start an unloaded squirrel cage induction motor without any starting device100% copper winding stc alternator with cheapest price
