Water Pump 10gpm/1500gpm for Building Safety

Complete fire pump products

AW series single-stage end-suction (axial intake) centrifugal pump is an energy-saving pump designed by teamwork in the whole nation, it is improved on a basis on model BA, B and other single-stage water centrifugal pump. The advantages: its hydraulic capability is distributed reasonably, wide option for user, conveniently check and repair, the efficiency and throw is up to advanced international level. This pump is suitable for industrial and city water supply, water drainage, and widely used for agricultural irrigation, transportation pure water or other liquids whihc physical and chemical nature is similar to pure water, and the temperature should not be higher than 80℃.

2.Range of Application

Applicable for the fire water in residence, hotels, office buildings, commercial buildings, factories and hospitals etc

3. Range of Performance
        Capacity: 5—200L/S
       Head:20—230m
       Power: 3—200kW

4. Working Condition

a. Applicable for trans ferring clear water or non-corrosive media whose physical and chemical characteristic is similar as clear water and solid insoluble matters less than 0.1%.

b. Medium temperature: -15℃~120℃.

c. Max. working pressure: XBD-DL PUMP: ≤2.5MPa, i.e. system pressure+ lift               d. head≤2.5MPa; XBD-LG PUMP: ≤2.OMPa;XBD-ISG PUMP:≤1.6MPa
e. Ambient temperature<40℃and relative temperature<95'C.

Pictures:

Certification:
