Manufacturer New 40CH 5.8G 600mW A/V Transmitting/Receiving System TS832 + RC832 RP-SMA

Manufacturer New 40CH 5.8G 600mW A/V Transmitting/Receiving System TS832 + RC832 RP-SMA thumbnail-1
Manufacturer New 40CH 5.8G 600mW A/V Transmitting/Receiving System TS832 + RC832 RP-SMA thumbnail-2
Manufacturer New 40CH 5.8G 600mW A/V Transmitting/Receiving System TS832 + RC832 RP-SMA thumbnail-3
Manufacturer New 40CH 5.8G 600mW A/V Transmitting/Receiving System TS832 + RC832 RP-SMA photo-1
Manufacturer New 40CH 5.8G 600mW A/V Transmitting/Receiving System TS832 + RC832 RP-SMA photo-2
Manufacturer New 40CH 5.8G 600mW A/V Transmitting/Receiving System TS832 + RC832 RP-SMA photo-3
US$ 42.00 - 42.00 MOQ: 10 Sets
Key Specifications
Get Latest Price
Type:
Helicopter
Power:
Other, Power
Material:
Other, Metal
Contact Supplier Request Quote Chat Now
Shenzhen Shijie Wireless Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Helicopter
Power Other, Power
Material Other, Metal
Scale Other, 1:1
Radio Control Style RC Hobby
Place of Origin Guangdong, China
Brand Name shijie wireless
Model Number TS832+RC832
Product Description
TS832 Specification: ( New 40CH with Race Band )
Item Name: TS832 transmitter
Frequency: 5.8G
Power input: 7.4-16V (3S Lipo suggested)
Transmitting Power: 600mA
Antenna Gain: 2db
Working Current: 220mA at 12V
Video Format: NTSC / PAL Auto
Video Bandwidth: 8M
Audio Bandwidth : 6.5M
Dimension: 54x 32x 10mm(excluding antenna)
Connector: transmitter module side RP-SMA jack, antenna RP-SMA plug

RC832 Specification: ( New 40CH with Race Band )
Item Name: RC832 receiver
Power Input: 12V
Working Current: 200mA max
Antenna Impedance: 50Ω
Antenna Gain: 2db
Video Impedance: 75Ω
Video Format: NTSC/PAL auto
Dimension:  80x 65 x15mm
Connector: receiver module side RP-SMA jack, antenna RP-SMA plug

Features:
40 channels choice to get the best transmitting quality.
Compatible with A,B,E ,F,R bands
Super small 200mA current for 600mW wireless transmitter power.
Smaller size with lighter weight.
40 CH compatible to all FPV 5.8g receivers.
5.8G 600mW 40 Channels AV wireless FPV  transmitter
600mW transmitter power assure 5KM distance in open area, 5-8 KM is available if work with the bigger gain antenna.

Package Included:
1 x TS382 transmitter
1 x RC832 receiver
2 x 5.8G 5DB antenna
3 x cable

Batch Production:
Manufacturer New 40CH 5.8G 600mW A/V Transmitting/Receiving System TS832 + RC832 RP-SMA

Different connectors can be chose:

Manufacturer New 40CH 5.8G 600mW A/V Transmitting/Receiving System TS832 + RC832 RP-SMA



Factory View:

Manufacturer New 40CH 5.8G 600mW A/V Transmitting/Receiving System TS832 + RC832 RP-SMA



Certifications:

Manufacturer New 40CH 5.8G 600mW A/V Transmitting/Receiving System TS832 + RC832 RP-SMAManufacturer New 40CH 5.8G 600mW A/V Transmitting/Receiving System TS832 + RC832 RP-SMA



Shipment way:

Manufacturer New 40CH 5.8G 600mW A/V Transmitting/Receiving System TS832 + RC832 RP-SMA
