Wileless stand alone smoke detector for addressable fire alarm system

Name: Wileless stand alone smoke detector for addressable fire alarm system
Brand: Asenware
Availability: InStock

FOB Price

USD $1 - $10 / Piece

100 Pieces(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China		Brand Name	Asenware
Model Number	AW-ASD2188

Wileless stand alone smoke detector for addressable fire alarm system

Specification:

Executive standard	GB4716-2005
Operating voltage	24V (pulse modulation)
Operating current	£¼300uA (monitoring status) or £¼1.5mA (alarm status)
Work indication	The red indicator will blink in the monitoring status or remain lit in the alarm status
Weight	about 70g
External dimensions	diameter: 100mm, height: 55mm (with the base)
Wiring method	non-polarity two-bus system (L1, L2)
Operating environment	Indoor, temperature: -10℃~+50℃; relative humidity: ≤95% (40℃ ±2℃, without condensation)
Coding mode	It can realize electronic coding via coder in situ. Address codes 1 to 324 are available for selection
Installation height	≤12m
Protection area	about 60m2. For details, see related provisions in GB50116-98 Code for Design of Automatic Fire Alarm System
Matched host machine	fire alarm control panel (such as AW-AFP2188)

Product pictures:

About us:

Why choose Asenware?

1.We have more than 10 years experiences in this field.

2.Our professional engineers are always engaging in developing new technology.

3.Meet customer demand is our consistent aim.

4.Our products are economic, user-friendly and easy maintenance.

5.Our all products shipped after testing by laboratories.

If you have any problems, feel free to contact us at any time!
