low cost addressable fire alarm system for repeater
Product features,
1,Each display panel is connected with a fire alarm control panel via a RS-48 bus.
At most 99 display panels may be connected with each RS-485 bus.
2,The display panels can display fire alarm messages or feedback messages only
rather than fault messages, action messages or other messages.
3,A fire alarm control panel may be used for setting the display area of a display panel.
The set display panel can display the fire alarm messages of the designated area (floor display) only.
Note,See the User’s Manual of the fire alarm control panel for the setting method
4,It can replace a JB-FSD-981 fire display panel in a 2100 system
Technical parameters
| 1. Executive standard: General Technical Conditions for Fire Indicating Panels (GB17429- 1998) |
| 2. Display capacity: Each display panel can display the fire alarm messages of floors -10~90 and at most 99 fire alarm messages or feedback messages. |
| 3. Wiring system: Four-wire system, power lines (+24V, GND) and RS485 signal lines (485A, 485B) |
| 4. Operating environment: Indoor; temperature: -10℃~+50℃; relative humidity: ≤95% (40℃, without condensation) |
| 5. Power supply: DC 24V ±20 % |
| 6. Overall power consumption: <3W |
| 7:Contact capacity: Relay dry contacts, normally open or normally closed, capacity: 1.25A/DC30V (resistive load) |
Appearance and dimensions
Q1: How about the quality of the products?
A: We produce every product with good quality materials, and test carefully to make sure stable quality before shipment.
Q2: Can I have a sample order?
B: Yes, Of course you can . we welcome sample order for your testing and checking products quality.Mixed samples are avaliable.
Q3: What is the shipping time?
C: Small Qty order needs 3-5 working days, big Qty order usually needs 10-5 working days after payments arriving. That's depends on order Qty.
Q4: How to proceed the order if I have logo to print?
D: We will prepare artwork for visual confirmation at first, if the color and position are alright,we will make print Logo sample from silk print factory and take picture for you to comfire before mass production.
