fire alarm button used for with two-bus control panel
Product features
1:It can realize complete electronic coding and in situ rewriting with help of a coder.
2:Designed with an upper cover and a lower cover, it can be installed, debugged and maintained conveniently.
3: It is designed with a two-wire fire telephone jack and is therefore more applicable to engineering application
4:Designed with passive output contacts, it can control other external equipment directly through an intermediate relay.
5:The pressing sheet on the manual call point will not get crushed after it is pressed, but can be reset by a special tool, so it can be used repeatedly
Technical parameters
| 1. Executive standard: GB19880-2005 |
| 2. Operating voltage: 24V (pulse modulation) |
|
3. Operating current: <300uA (in the monitoring status); <2mA (in the action status) |
| 4. Output contact: Normally open contact; capacity: 0.1A/30VDC |
| 5. Weight: About 120g |
| 6. Wiring method: nonpolar two-bus system (L1, L2) |
|
7. Operating environment: Indoor, temperature: -10℃~+50℃; relative humidity: ≤95% (40℃±2℃, without condensation) |
|
8. Coding method: It can realize online coding with the help of a coder and without the necessity of disassembling the bus Address codes 1 to 324 are available for selection. |
|
9. Telephone jack: Two-wire fire telephone jack (equipped with a standard 6.3 single-track audio connector). |
|
10. Starting part: A plastic pressing sheet that may be used repeatedly. It can be manually reset with a special tool after being pressed. |
| 11. Starting mode: Press the pressing sheet manually. |
|
12. Indicator: The red ALARM indicator will blink in the inspection status or remain lit in the alarm status; the PHONE indicator will blink when a fire ,telephone loop is connected, otherwise it will be out. |
| 13. Matched host machine: fire alarm control panel (such as AW-AFP2188) |
ASENWARE was established in 2005. We have focused on the Fire Alarm and BMS(Building Management System) over 11 years. Our headquarter is in London, UK.
We develop and manufacture addressable fire alarm system, conventional fire alarm system, fire extinguisher, CCTV camera and DVR, and DDC for HVAC system.
Based on our ISO9001 quality control system and our experiences in BMS and NDT, we integrated a series of products in our E-Shop; they are cost-effective and guaranteed quality.
We keep our best service for our customers, and have a rich experienced engineer team to design and install for overseas projects.
Q1: How about the quality of the products?
A: We produce every product with good quality materials, and test carefully to make sure stable quality before shipment.
Q2: Can I have a sample order?
B: Yes, Of course you can . we welcome sample order for your testing and checking products quality.Mixed samples are avaliable.
Q3: What is the shipping time?
C: Small Qty order needs 3-5 working days, big Qty order usually needs 10-5 working days after payments arriving. That's depends on order Qty.
Q4: How to proceed the order if I have logo to print?
D: We will prepare artwork for visual confirmation at first, if the color and position are alright,we will make print Logo sample from silk print factory and take picture for you to comfire before mass production.
