50T precise small injection molding machine
We are a small plastic injection molding machine manufacturer of which clamp force ranges from 32T to 270T, injection weight from 20g to 800g.The machines can be applied to produce plastic gears, colour chips for masterbatch or pigments,pvc fitting,Junction box, zip ties, small plastic toys and as many as other plastic parts.
Main parameters of 50T injection molding machine as below;
| Items | Parameter | Unit | Parameter Value (SSF500) | |
| Injection Unit | Screw diameter | mm | A | B |
| 28 | 30 | |||
| Screw L/D ratio | L/D | 19 | 17.7 | |
| shot volumn (theoretical) | Cm3 | 70 | 80 | |
| injection weight(PS) | g | 64 | 73 | |
| plasticizing capacity | g/s | 6.9 | 7.7 | |
| injection rate | g/s | 43 | 49 | |
| injection pressure | Mpa | 224 | 195 | |
| screw speed | rmp | 200 | ||
| Clamping unit | clamp force | KN | 500 | |
| open stroke | mm | 250 | ||
| space between bars (W*H) | mm | 290*270 | ||
| max mould height | mm | 300 | ||
| min mould height | mm | 100 | ||
| ejector stroke | mm | 65 | ||
| ejector force | KN | 20 | ||
| ejector number | PC | 1 | ||
| mould align diameter | mm | 100 | ||
| Others | max pump pressure | Mpa | 16 | |
| pump motor power | KW | 5.5 | ||
| heating power | KW | 4.7 | ||
| machine dimension | m | 3.2*1.1*1.6 | ||
| machine weight | T | 1.9 | ||
| oil tank capacity | L | 115 | ||
Standard features;
Double-cylinder balanced injection system;
Multi-stage pressure &speed injection;
Back pressure adjustment device;
Low pressure mold protection;
Single hydraulic core pulling and inserting;
Multiple hydraulic ejector knock-out;
Mechanical, electrical safety device;
Auto lubrication system;
Hydraulic pressure full proportional control;
Computer control system;
Molding data memory system;
Automatic mould adjust function.
Optional auxiliary
Robot system
Hopper dryer
Auto loader
Hopper Magnet
Mold clamps
Water cooler
Plastic dehumidizer
Mold temperature controller
Oil temperature controller
Oil bypass filter
Spare parts;
1.Nozzle
2.Lubricate oil
3.Seal rings(5pcs)
4. Tool box
5. Other tools such as spanner, straight screwdrivers;
6. Crash pad
Agents wanted
In order to bring our machines to more customer worldwidely, we are sincerely to invite distributors to get exclusive agency agreement from us, we promise to provide you the competitive price with good services.
What we request you is to have a robust sales and maintetance team for customer end machine instalaltion and debugging, provide on time aftersales service to customers, to make our brand known in your market.
We have signed agency agreements with distributors in Argentina, Denmark,Poland,Russia,Turkey.
We would like to open our market to Brazil, Chile,Colombia, India, Thailand,Malaysia,Indonesia and other countries.
Welcome your discussion on our cooperation.
If you have any query about our injection molding machine, just contact me at any time Alexis Liao Mobile photo:+8613806673276(whats app&we chat ID)
QQ:1159033100
