Help CenterSmall and Precise 38T Moulding Machine
Related Products
-
SSF380-K5 Injection Molding MachineUS$ 1 - 50,000MOQ: 1 Set -
Small Sized Plastic Injection Molding MachineUS$ 1 - 50,000MOQ: 1 Set
-
90Ton Injection Moulding Machine for HDPE Plastic PartsUS$ 1 - 50,000MOQ: 1 Set
-
Servo Motor 148T Injection Molding MachineUS$ 1 - 50,000MOQ: 1 Set
-
148TON New Color Injection Moulding MachineUS$ 1 - 50,000MOQ: 1 Set
Since the establishment in 2002, our Shuangsheng brand has obtained good reputation from customers at home and abroad, our small sized series injection molding machines are featured with small, precise, professional and stable.
Machines size ranges from 32Tons to 270Tons, with injection weight from 20g to 800g, the machines are widely applied to produce small precise gears, masterbatch or pigment color chips, PVC fittings, PET preforms, bottle caps, bowls, plastic toys such as Barbie, cars, eletrical junction boxes, sockets, nylon zip ties and other plastic products that of injection weight within 800Grams.
Shuangsheng SSF-series small injection molding machine is a strong open platform, which can meet the customer's special request, like adding special features so as to suit all kinds of process techniques.
In order to provide good service to customers, we have established good cooperation with mold and auxiliaries supplier, they can provide the best quality molds, hopper dryer,chiller,autoloader,crusher for you, that works on well with our machines.
Main products;
A.Fixed pump injection molding machine(SSF-K5)
B.Servo motor energy saving injection molding machines(SSF-S)
C.Special purpose machine for lab test, of which is the first choice for masterbatch and pigment manufacturers.
D.Product range:32Ton~270Ton
Main parameters of Small and precise 38T moulding machine as below;
| Items | Parameter | Unit | Parameter Value (SSF380) | |
| Injection Unit | Screw diameter | mm | A | B |
| 27 | 30 | |||
| Screw L/D ratio | L/D | 18.4 | 16.5 | |
| shot volumn (theoretical) | Cm3 | 48 | 58 | |
| injection weight(PS) | g | 44 | 53 | |
| plasticizing capacity | g/s | 4.3 | 5.9 | |
| injection rate | g/s | 35 | 43 | |
| injection pressure | Mpa | 187 | 151 | |
| screw speed | rmp | 170 | ||
| Clamping unit | clamp force | KN | 380 | |
| open stroke | mm | 235 | ||
| space between bars (W*H) | mm | 240*240 | ||
| max mould height | mm | 270 | ||
| min mould height | mm | 80 | ||
| ejector stroke | mm | 60 | ||
| ejector force | KN | 17.5 | ||
| ejector number | PC | 1 | ||
| mould align diameter | mm | 80 | ||
| Others | max pump pressure | Mpa | 14 | |
| pump motor power | KW | 4 | ||
| heating power | KW | 3.2 | ||
| machine dimension | m | 2.9*1.0*1.4 | ||
| machine weight | T | 1.35 | ||
| oil tank capacity | L | 90 | ||
Injection molding machine standard features;
Double-cylinder balanced injection system;
Multi-stage pressure &speed injection;
Back pressure adjustment device;
Low pressure mold protection;
Single hydraulic core pulling and inserting;
Multiple hydraulic ejector knock-out;
Mechanical, electrical safety device;
Auto lubrication system;
Hydraulic pressure full proportional control;
Computer control system;
Molding data memory system;
Automatic mould adjust function.
Injection molding machine optional auxiliary
Robot system
Hopper dryer
Auto loader
Hopper Magnet
Mold clamps
Water cooler
Plastic dehumidizer
Mold temperature controller
Oil temperature controller
Oil bypass filter
Injection molding machine spare parts;
1.Nozzle
2.Lubricate oil
3.Seal rings(5pcs)
4. Tool box
5. Other tools such as spanner, straight screwdrivers;
6. Crash pad
We make injection molding machines strictly follow ISO9001:2008 quality requirements, per customers's special requirements, CE also can be optional.
Injection molding machine warehouse, enough stock to make sure can deliver per customer's requirements;
Robust Mold platens of plastic injection molding machines, we machined the critical dimensions by ourselves and our-sourced casting;
We shuangsheng plastic machinery respects staffs and values partnership of each customer, each cooperators, that why we can grow smoothly and steadily even the international ecomonic situation is not so optimistic.
The orgnization chart of our company, average working life of the staffs is 8 years.
Organization chart
If you have any query about our injection molding machine, just contact me at any time
Alexis Liao
Mobile photo:+8613806673276(whats app&we chat ID)
QQ:1159033100
