Help CenterServo Motor 148T Injection Molding Machine
Related Products
-
148TON New Color Injection Moulding MachineUS$ 1 - 50,000MOQ: 1 Set -
50T Energy Saving Small Plastic Injection Moulding MachineUS$ 11 - 50,000MOQ: 1 Set
-
Mini Injection Molding MachineUS$ 1 - 50,000MOQ: 1 Set
-
148TON Servo Injection Molding MachineUS$ 1 - 50,000MOQ: 1 Set
-
Small Plastic Injection Machine for School TenderUS$ 1 - 50,000MOQ: 1 Set
Since the establishment in 2002, our Shuangsheng brand has obtained good reputation from customers at home and abroad, our small sized series injection molding machines are featured with small, precise, profeesional and stable.
Machines size ranges from 25Tons to 168Tons, with injection weight from 20g to 400g, the machines are widely applied to produce small precise gears, masterbatch or pigment color chips, PVC fittings, PET preforms, bottle caps, bowls, plastic toys such as Barbie, cars, eletrical junction boxes, sockets, nylon zip ties and other plastic products that of injection weight within 400Grams.
Shuangsheng SSF-series small injection molding machine is a strong open platform, which can meet the customer's special request, like adding special features so as to suit all kinds of process techniques.
In order to provide good service to customers, we have established good cooperation with mold and auxiliaries supplier, they can provide the best quality molds, hopper dryer,chiller,autoloader,crusher for you, that works on well with our machines.
The Main products we are making;
A.Fixed pump injection molding machine(SSF-K5)
B.Servo motor energy saving injection molding machines(SSF-S)
C.Special purpose machine for lab test.
Main parameters of 148T injection machine as below;
| Items | Parameter | Unit | Parameter Value (SSF1480-S) | ||
| Injection Unit | Screw diameter | mm | A | B | C |
| 38 | 42 | 45 | |||
| Screw L/D ratio | L/D | 22.1 | 20 | 18.6 | |
| shot volumn (theoretical) | Cm3 | 226 | 277 | 318 | |
| injection weight(PS) | g | 206 | 252 | 289 | |
| injection rate | g/s | 94 | 115 | 132 | |
| injection pressure | Mpa | 208 | 171 | 149 | |
| screw speed | rmp | 185 | |||
| Clamping unit | clamp force | KN | 1480 | ||
| open stroke | mm | 380 | |||
| distance between tie bars (W*H) | mm | 410*410 | |||
| max mould thickness | mm | 450 | |||
| min mould thickness | mm | 160 | |||
| ejector stroke | mm | 120 | |||
| ejector force | KN | 50 | |||
| ejector number | PC | 5 | |||
| dia of mould location hole | mm | 125 | |||
| Others | max pump pressure | Mpa | 16 | ||
| pump motor power | KW | 13 | |||
| heating power | KW | 9.3 | |||
| machine dimension | m | 4.5*1.35*1.9 | |||
| machine weight | T | 4 | |||
| oil tank capacity | L | 250 | |||
Standard features;
Double-cylinder balanced injection system;
Multi-stage pressure &speed injection;
Back pressure adjustment device;
Low pressure mold protection;
Single hydraulic core pulling and inserting;
Multiple hydraulic ejector knock-out;
Mechanical, electrical safety device;
Auto lubrication system;
Hydraulic pressure full proportional control;
Computer control system;
Molding data memory system;
Automatic mould adjust function.
Optional auxiliary
Robot system
Hopper dryer
Auto loader
Hopper Magnet
Mold clamps
Water cooler
Plastic dehumidizer
Mold temperature controller
Oil temperature controller
Oil bypass filter
Spare parts;
1.Nozzle
2.Lubricate oil
3.Seal rings(5pcs)
4. Tool box
5. Other tools such as spanner, straight screwdrivers;
6. Crash pad
Parts that can be made by this machine but not limited;
CE and ISO quality certificate.
Organization Chart
If you have any query about our injection molding machine, just contact me at any time
Alexis Liao
Mobile photo:+8613806673276(whats app&we chat ID)
QQ:1159033100
