Small injection moulding machine SSF500K5
We have manufacturered 4 sets SSF500K5 per Argentina's agent order, except standard character, the machine also features with;
1.Well brand components of valves;
2.Spanish language for localization;
3.Mold height auto adjustment;
4.Screw diameter 30mm;
5.Bi-metal screw and barrel;
Main parameters of 50T injection molding machine as below, you can have 2 kind of screw specification for selection;
| Items | Parameter | Unit | Parameter Value (SSF500) | |
| Injection Unit | Screw diameter | mm | A | B |
| 28 | 30 | |||
| Screw L/D ratio | L/D | 19 | 17.7 | |
| shot volumn (theoretical) | Cm3 | 70 | 80 | |
| injection weight(PS) | g | 64 | 73 | |
| plasticizing capacity | g/s | 6.9 | 7.7 | |
| injection rate | g/s | 43 | 49 | |
| injection pressure | Mpa | 224 | 195 | |
| screw speed | rmp | 200 | ||
| Clamping unit | clamp force | KN | 500 | |
| open stroke | mm | 250 | ||
| space between bars (W*H) | mm | 290*270 | ||
| max mould height | mm | 300 | ||
| min mould height | mm | 100 | ||
| ejector stroke | mm | 65 | ||
| ejector force | KN | 20 | ||
| ejector number | PC | 1 | ||
| mould align diameter | mm | 100 | ||
| Others | max pump pressure | Mpa | 16 | |
| pump motor power | KW | 5.5 | ||
| heating power | KW | 4.7 | ||
| machine dimension | m | 3.2*1.1*1.6 | ||
| machine weight | T | 1.9 | ||
| oil tank capacity | L | 115 | ||
Except standard machines, you can also buy the neighbour auxiliaries from us if you have the demand;
Robot system, there is connection of our machine to robot;
Hopper dryer,we have reliable supplier to provide good quality hopper dryer with competitive price;
Auto loader,
Hopper Magnet
Mold clamps
Water cooler
Plastic dehumidizer
Mold temperature controller
Oil temperature controller
Oil bypass filter
Spare parts, they will deliver together with machines for free;
1.Lengthened Nozzle
2.Lubricate oil or grease oil
3.Seal rings
4.Tool box for machine disassemble
5.Crash pad for machine fix to the ground.
We make injection molding machines strictly follow ISO9001:2008 quality requirements, per customers's special requirements, CE also can be optional.
World well know valves for proportional, directional and back pressure;
If you have any query about our injection molding machine, just contact me at any time Alexis Liao Mobile photo:+8613806673276(whats app&we chat ID)
QQ:1159033100
