Solid Waste Fired Steam Boiler

Name: Solid Waste Fired Steam Boiler
Brand: HUAYUAN
SKU: 112616097
Availability: InStock

US$ 40,000 - 2,000,000 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Natural Circulation

Usage:

Other, Industrial, Power station

Linyi Shiningasia International Trade Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

QINGDAO

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Natural Circulation

Usage Other, Industrial, Power station

Structure Water Tube

Pressure High Pressure

Style Other, Horizontal, Assembly

Fuel Other, Biomass or Coal, Solid Waste

Place of Origin Shandong, China

Brand Name HUAYUAN

Model Number LC 35-5-1.25

Output Steam

Dimension(L*W*H) 5470*2830*3550mm

Weight 23T

Certification ASME

After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.High heat efficiency steam boiler
2.Stable working perfformance
3.Long design running life

LC style Solid Waste Burned Boiler

Boiler type	LC35-5-1.25	LC40-5-1.25	LC60-6-1.25	LC60-8-1.25	LC120-12-1.25
Rated output(t/h)	5	5	6	8	12
Rated pressure(MPa)	1.25	1.25	1.25	1.25	1.25
Rated steam temp(°c)	194	194	194	194	194
Combustion mode	chain layer	chain layer	chain layer	chain layer	chain layer
Fuel	coal,firewood	waste of paper material(humidity<20%,sand solid<5%)	waste of paper material(humidity<20%,sand solid<5%)	waste of paper material(humidity<20%,sand solid<5%)	waste of paper material(humidity<20%,sand solid<5%)
Grate area(m2)	10	8.3	8.9	11.2	18
Heated surface of boiler(m2)	188.9	232.2	186	254.7	372.6
Heated surface of boiler tail(m2)	99.3	99.3	255	99.3	84.97
Size(mm)	547028303550	632032303530	875032403550	777034003550	820035502930
Weight(T)	23	28	34	34	49
Day treat waste amount	35	40	60	60	120
According to users' fuel ,can specially design .

Advantage

The boiler shall adopt double drum, monolayer arrangement, compact structure, as well as large heating surfaces which are more 10% than those of same kinds of products, featuring the following advantages such as sufficient output, safe and reliable operation ,short construction period, and low installation cost ect.
The design of cyclone reburning chamber in furnace resulted in the decrease of dust contained in the flue gas .At the same time, incandescent carbon black particles shall burn further, enhancing the boiler thermal efficiency, and decreasing gas blackness ,as a result, the gas emission concentration shall meet the requirements of grade A environmental protection area.
The grate shall employ the technology patent of small roller structure, boundary grate and so on ,improving the operation reliability of the boiler.
Since the adoption of technology patent for the sealed wind chamber and bilateral grate air register, and the application of machining cone seal structure to grate adjusting air equipment, the sensitivity of the grate shall be improved.
The boiler was awarded the following titles: first class products of mechanical and electrical department, excellent energy-saving products promoted by state, excellent energy-saving products of Shandong province.
According to the customers’ requirements, the layering burn device and other energy saving equipments, implemented in state, shall be matched.
