4.2MW Packaged Hot Water Boiler On Sale
USD $80,000 - $120,000
/ Set
1 Set(Min.Order)
- 500 Set / Sets per Month
- QINGDAO/LIANYUNGANG
- T/T Credit Card
You May Like
- Mini animal feed grinding machine , corn powder hammer mill
- Mini type corn hammer mill , feed grinding machine for sell
- Factory direct sell small feed hammer mill , corn grinding machine
- Large capacity gum arabic hammer mill with cyclone
- Double Win agricultural hammer mill for sale,grain hammer mills for sale
- Ce approval Rice husk hammer mill machine/corn hammer mill/maize grinding hammer mill
Product Details
Condition: | New | Type: | Natural Circulation | Usage: | Other, Industrial, Industry/Power station |
Structure: | Water Tube | Pressure: | Low Pressure | Style: | Other, Horizontal, Packaged/Assembly |
Fuel: | Other, Coal-fired, Coal | Place of Origin: | Shandong, China | Brand Name: | HUAYUAN |
Model Number: | SZL 4.2-0.7/115/70 | Output: | Hot Water | Dimension(L*W*H): | 5370*2970*3550mm |
Weight: | 36T | Certification: | GB | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Hot Water Boiler
- The boiler shall adopt double drum, monolayer arrangement, compact structure, as well as large heating surfaces which are more 10% than those of same kinds of products, featuring the following advantages such as sufficient output, safe and reliable operation ,short construction period, and low installation cost ect.
- The design of cyclone reburning chamber in furnace resulted in the decrease of dust contained in the flue gas .At the same time, incandescent carbon black particles shall burn further, enhancing the boiler thermal efficiency, and decreasing gas blackness ,as a result, the gas emission concentration shall meet the requirements of grade A environmental protection area.
- The grate shall employ the technology patent of small roller structure, boundary grate and so on ,improving the operation reliability of the boiler.
- Since the adoption of technology patent for the sealed wind chamber and bilateral grate air register, and the application of machining cone seal structure to grate adjusting air equipment, the sensitivity of the grate shall be improved.
- The boiler was awarded the following titles: first class products of mechanical and electrical department, excellent energy-saving products promoted by state, excellent energy-saving products of Shandong province.
- According to the customers’ requirements, the layering burn device and other energy saving equipments,implementedinstate, shall be matched.
Parameter List
Boiler type | SZL4.2-0.7/95/70-AII | SZL5.6-0.7/95/70-AII | SZL7.0-1.0/115/70-AII | SZL10.5-1.0/115/70-AII | SZL5.6-0.7/95/70-AII(Q) | SZL14-1.0/115/70-AII | SZL7(0)-1.0/115/70-1.25-AII |
Rated capacity(MW) | 4.2 | 5.6 | 7.0 | 10.5 | 5.6 | 14 | 7(10) |
Rated effuent temperature(°c) | 95(60) | 95 | 115 | 115 | 95 | 115 | 115(94) |
Rated return water temperature(°c) | 70(45) | 70 | 70 | 70 | 70 | 70 | 70 |
Combusion mode | Chain grate | Chain grate | Chain grate | Chain grate | Chain grate | Chian grate | Chain grate |
Applicable coal | AII AIII | AII AIII | AII AIII | AII AIII | AII AIII Gas | AII AIII | AII AIII |
Grate area(m2) | 7.23 | 9.9 | 11.99 | 17.38 | 9.9 | 21.33 | 11.99 |
Heat surface of boiler(m2) | 157.6 | 240.2 | 243.2 | 324 | 240.2 | 440 | 232.3 |
Heated surface of boiler tail(m2) | 174.4 | 236 | 233 | 52.7 | |||
Coal consumption(kg/h) | 896.6(943) | 1186.6 | 1507.6 | 2258 | 1186 | 2938 | 1407(1507.3) |
Exhaust gas temperature(°c) | 175(161) | 175 | 170 | 170 | 175 | 170 | 195(170) |
Dust emission concentration(mg/Nm3) | <80 | <80 | <80 | <80 | <80 | <80 | <80 |
Thermal effciency(%) | 79.2 | 79.59 | 82.17 | 82.3 | 79.59 | 82.5 | 78.28 |
Transfer size(L*W*H)mm | 5370*2970*3550 | 6720*3400*3540 | 8800*3230*2600 | 9900*3400*3530 | 6720*3400*3540 | 10700*3550*3400 | 7570*3230*3540 |
Weight(T) | 36 | 26.4 | 30.51 | 36 | 26.4 | 41 | 33.3 |
Installed size(L*W*H)mm | 8370*5330*3860 | 9000*5000*5600 | 11320*3600*5400 | 13000*4500*5800 | 9000*5000*5600 | 14000*4730*7820 | 11800*4250*5750 |
Rated working pressure(MPa) | 0.7 | 0.7 | 1 | 1 | 0.7 | 1 | 1(1.25) |
