Solid Waste Steam Boiler

Name: Solid Waste Steam Boiler
Brand: AAA
Availability: InStock

FOB Price

US$ 150,000 - 200,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Natural Circulation
Usage	Other, Industrial, Industry/Power station	Structure	Water Tube
Pressure	Low Pressure	Style	Other, Horizontal, Packaged/Assembly
Fuel	Other, Solid waste	Place of Origin	Shandong, China
Brand Name	AAA	Model Number	LC35-5.1.25
Output	Steam	Dimension(LWH)	5470283003550mm
Weight	23T	Certification	ASME
After-sales Service Provided	Engineers available to service machinery overseas

LC style Solid Waste Burned Boiler

Boiler type	LC35-5-1.25	LC40-5-1.25	LC60-6-1.25	LC60-8-1.25	LC120-12-1.25
Rated output(t/h)	5	5	6	8	12
Rated pressure(MPa)	1.25	1.25	1.25	1.25	1.25
Rated steam temp(°c)	194	194	194	194	194
Combustion mode	chain layer	chain layer	chain layer	chain layer	chain layer
Fuel	coal,firewood	waste of paper material(humidity<20%,sand solid<5%)	waste of paper material(humidity<20%,sand solid<5%)	waste of paper material(humidity<20%,sand solid<5%)	waste of paper material(humidity<20%,sand solid<5%)
Grate area(m2)	10	8.3	8.9	11.2	18
Heated surface of boiler(m2)	188.9	232.2	186	254.7	372.6
Heated surface of boiler tail(m2)	99.3	99.3	255	99.3	84.97
Size(mm)	547028303550	632032303530	875032403550	777034003550	820035502930
Weight(T)	23	28	34	34	49
Day treat waste amount	35	40	60	60	120
According to users' fuel ,can specially design .

Packaging & Shipping
