Specifications
1. Protection Degree: IP 662. ATEX,IEC Ex certification
3. SMC material
Main technical data:
Ex mark: Ex ed IIC T5/T6
DIP A21 TA, T5/T6
Intended use: Can be used in zone 1 and zone 2
Can be used in zone 21 and zone 22
Degree of protection: IP65
Rated voltage:380 / 400V;50 / 60Hz
Main switch: CZ0513 Flameproof isolation switch module
Maximum current is 40,80,125/180A
Branch circuit:CZ0511-BL Flameproof high on-off miniature
Maximum current is 40A
CZ0512 Flameproof magnetic starter module
Rated current of AC contactor: 22.5
Setting range of over load trip of thermorelay::0.1 ~ 24A
Cable enties:2 Circuits Inlet: 1×M40
Cable outside diameter: Φ17-28mm
Outlet: 3×M25
Cable outside diameter: Φ8-17mm
4 Circuits Inlet:1×M50
Cable outside diameter: Φ22-35mm
Outlet:6×M25
Cable outside diameter: Φ8-17mm
Mounting way: Pendant type
Material of enclosure: Anti-static glass fibre reinforced polyester (SMC)
