Specifications
1.Classical High reliable Meter Test Bench2.3--60 meter positions available
3.support all test items as per covering IEC st
DZ603-6 Three Phase Energy Meter Test Bench
Features:
1. Shall carry out completely automatic calibration items such as running with no load, starting, basic error, standard distortion and 24 hours variation etc according to testing regulations: four quadrant: positive, negative, active or reactive error test, automatic shift the input of all kinds of pulse.
2. The tested meters maybe same specification but different communication protocols.
3. Shall carry out tests such as demand cycle and its display, time interval error, register combined error and daily error.
4. Communication test, GPS broadcast time calibration, meter data verification, regarding record meter number.
5. According to regulations, carry out various influence value test, voltage falling and interruptions shall be carried out.
6. Automatically adjust black spot, calculate time for starting test and running with mo load test according to regulations.
7. Shall adopt fixed time and fixed quality burden methods to carry out the reading test, and different time interval with different burden tests are available.
8. Shall display the voltage and current wave diagram with same phase: shall set and measure 2~21 times harmonic wave and measure the distortion degrees.
9. Data be processed and printed automatically, and the table lay out shall be set freely according to user's requirements, transfer data by all M2S port.
10. Support: bar code input, error curve, error limit setting, multi-mode calibration plans and equipment management authority etc.
Specifications:
1. Voltage output ranges: 57.7V, 100V, 220V, 380V.
2. The current ranges: 1mA, 5mA, 10mA, 25mA, 50mA, 0.1A, 0.5A, 1A, 2.5A, 5A, 10A, 20A, 50A, 100A.
3. The voltage and current adjusting resolution: 0.01% X tap position.
4. The voltage and current adjusting scope: 0120% X tap position.
5. Output phase adjusting scope: 0359.99°, adjusted resolution is 0.01°, output accuracy: ±0.05°.
6. Output frequency adjusting scope: 45.0065.00Hz, adjusted resolution is 0.01Hz, accuracy: ±0.05Hz..
7. Output current and voltage stability: 0.05%, output power stability: 0.05%.
8. .Output voltage and current distortion: <0.5%.
9. Output power: voltage: 280VA/phase, current: 280VA/phase.
10. Accuracy class: 0.01, 0.02, 0.03, 0.05.
11. Power supply: 220±10% (or as per your request), AC50Hz.
1. We can produce the single phase meter test bench/single phase energy meter instrument/single phase electricity meter test equipment according to client's requirement.
2. Good after-sale service, and good quality.
3. All our products can test all items such as Per IEC and ANSI
Founded in 1996, SMS Electric Co., Ltd. Zhengzhou is a hi-tech enterprise, which specializes in the research & development (R&D) and production of energy meters, energy meter test benches, automated energy meter test line, energy meter assembly line, reference standard energy meters and instrument transformers, etc
With the development for years, we have possessed 9 series and 100 variety of energy meters, energy meter test benches, automated energy meter test line, energy meter assembly line, reference standard energy meters, and instrument transformers with annual production capacity of USD40,200,000, of which home market takes up about 83.%, while the overseas market takes about 17%.
Now, our sales network covers worldwide market and our products have been sold well all over the world, such as Denmark, Serbia, Brazil, Colombia, India, South Korea, Vietnam, Qatar, Mongolia, Taiwan, Egypt, Ethiopia, etc.
SMS creates excellent products to benefit the customers
SMS creates glorious achievements to benefit the society
SMS creates high value to benefit your life
SMS welcome you!
Add: No.85, The Fifth Street, Economic & Technological Development Zone, Zhengzhou City, PRC
Skype:rachelzhang1992
Mobile: +86-158-38316839 ; Fax: +86-371-67391399;
Website: /
1. What is the advantages of your products?
Thanks for your inquiry. Our products' advantages is that all products achieve the standard of IEC and ANSI.
And our goods have been exported to many countries in the world, such as Korea, India, Russion, Pakistan, Vietnam ans so on. The quality is excellent that it wins lot reputation for us.
2. What is the shelf life for your products?
Thanks for your consideration. The shelf life of our products is 3 years. (Our company is responsible for the repairing and maintaining free of charge)
3. What terms of trade your company accept?
Thanks for your consideration. Our company accepts T/T, L/C, Western Union. Thanks for your understanding.
