Specifications
1.Boiler provide heating&hot water supply2.Export to Russia,Ukraine,Iran,etc
3.High quality components with CE certificate
Water Heater Model:24-BTA(V)
1.Water heater main application:
1).Boiler provide heating&hot water supply for24kw
2).European Technology
3).High quality components with CE certificates
4). High Efficiency & Gas-saving, export to Russia,Ukraine,Iran,etc
2.Safety features:
1).Triple overheat protection.
2).Flameout protection.
3).Reignition function.
4).Defer ignition function.
5).Anti-freezing function .
6).Anti-lock function for pump.
7).Overload protection for pump.
8).Lightning strike protection.
9).Overload protection for control system.
10).Safety release function.
11).Automatic circulation function of pump.
12).Self-diagnostic function.
13).Safety lock function.
14).Automatic by-pass valve
15).Gas Boiler (24KW)
16).EUTechnology
17).Supply Both Heating
3.Technology parameter:
| Product Model | Unit | L1PB24-BTA(V) | ||
| Rated Heat Input | Kw | 24 | ||
| Min. Heat Input | Kw | 7.2 | ||
| Rated Heating Heat Output | Kw | 21.5 | ||
| Min. Heating Heat Output | Kw | 5.8 | ||
| Rated Output Hot Water Difference of temperature =30K | Kg/min | 10 | ||
| Gas Type | NG | |||
| Rated Gas Pressure | Pa | 2000 | ||
| Heating Systerm Water Pressure Range | Mpa | 0.05~0.3 | ||
| Safety Valve Openning Water Pressure | Bar | 3 | ||
| Domestic Hot Water Systerm Pressure Range | Mpa | 0.05~0.6 | ||
| The Water Cycle Way Of Heating | Built-in Closed Water Tank | |||
| Water Temperature Adjustment Range | Heating Water Output | °C | 40~80 | |
| Domestic Hot Water Output | °C | 30~60 | ||
| Heat Efficiency | % | 88-95% | ||
| Max.Power Input | W | 108 | ||
| Power Supply | V/Hz | AC220V 50Hz | ||
| Pump lift | m | 6 | ||
| Expansion tank capacity | L | 8 | ||
| Insulation Grade | Ⅰ | Ⅰ | ||
| Index Of Protection | IPX4D | IPX4D | ||
| Exhaust Way | Forced Exhaust | |||
| Outside Diameter and Inside Diameter Of Exhaust Smoke Gas | mm | Φ90/Φ60 | ||
| Max.Permissible Flue Length | m | 3 | ||
| Flue Pipe Length Reduction For Elbow | 90°Elbow | m | 1 | |
| 45°Elbow | m | 0.5 | ||
| Fittings | Central heating fitting | Inch | G3/4 | |
| DHW fitting | Inch | G1/2 | ||
| Gas fitting | Inch | G3/4 | ||
| Reference heating square | SQM | <140 | ||
| N.W | Kg | 40 | ||
| G.W | Kg | 43 | ||
| External Dimensions | mm | 750*440*330 | ||
| Packing Size | mm | 860*540*440 | ||
| Loading Quantity | 20ft | Pcs | 135 | |
| 40FT | Pcs | 260 | ||
| 40HQ | Pcs | 330 | ||
3.Warranty:
1).1 year warranty
2).Provide the spare parts for free of charge with some easy broken
3).We can replace it if the product quality is confirmed cause of ours responsibility
More than 10 years experience specialize in wall hung gas boiler
OEM & ODM are welcome!
