8inch 500nits 1024*600 lvds interface high brightness capacitive touch screen lcd with CTP

FOB Price

Negotiable / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China		Brand Name	Wilcon
Model Number	SW080NA-08A-CTP		Type	Other, TFT, TFT

8.0inch TFT LCD module

LCD specification

Part 1:LCD parameters
1	Product name	8.0inch lcd module
2	Model number	SW080NA-08A-CTP
3	Size	8.0INCH
4	Type	TFT
5	Viewing angle	6:00
6	Display scale	16:9
7	Display mode	Normally white, Transmissive
8	Resolution	1024*600
9	Piexel pitch	0.1725(W)*0.1656(H)
10	Dimension	192.8116.97.9mm
11	Active area	176.64*99.36
12	Color	16.7M
13	Color arragement	RGB
14	Interface	LVDS
17	Response time	30ms
18	Contrast ratio	700:1
19	Brightness	500cd/m2
20	VDD	3.3V
21	Backlight	LED
22	Backlight color	White
23	LED lifetime	20000hours
24	Voltage for LED	9.9V
25	Current for LED	360mA
26	Consumption	/
27	Module weight	/
28	Drive IC	/
29	Interface connect type	connector type
30	Surface tratement	Plain
31	Pin number	40PINS
32	Warranty	12 months
33	Packing material	Box
34	Shipment	ExpressAirSea

Part 2:Operation Speficifactions
1	Operature Temperature	-20----70℃ degrees
2	Storage Temperature	-30----80℃ degrees

Part 3:Touch panel
1	Touch	capacitive touch panel

LCD PICS

LCD structure

CTP structure

Packaging & Shipping

Our Services
