0.96inch 128*64 SSD1306 controller oled light screen mounted 7pins SPI interface board
Negotiable
/ Piece
1 Piece(Min.Order)
- 10000 Piece / Pieces per Month
- Shenzhen
- Credit Card
You May Like
-
negative segment character running machine lcd display,practical STN,blue backlight, fitness equipment
-
digital fire alarm installation module display, HTN segment display with blue led lcd panel
-
negative autoreclose circuit-breaker lcd display, segment module with blue led
-
charger negative character lcd display,white led ,battery segment small flexible display
-
character small charger lcd display ,custom battery display ,white led
-
segment positive temperature time clock lcd display,blue TN white backlight
Product Details
| Place of Origin: | Guangdong, China | Brand Name: | Wilcon | Model Number: | SW096D-SV01 |
| Type: | Other, OLED, OLED |
Product Description
0.96inch 128*64 micro oled screen with SSD1306 controller
LCD specification
| Part 1:LCD parameters | ||
| 1 | Product name | 0.96inch OLED |
| 2 | Model number | SW096D-SV01-B |
| 3 | Size | 0.96INCH |
| 4 | Type | OLED |
| 5 | Viewing angle | IPS |
| 6 | Display scale | 2:1 |
| 7 | Display mode | / |
| 8 | Resolution | 128*64 |
| 9 | Piexel pitch | 0.17 (W) x 0.17 (H) |
| 10 | Dimension | 26.7*19.26*1.4mm |
| 11 | Active area | 21.74*10.86mm |
| 12 | Color | Blue/white |
| 13 | Color arragement | / |
| 14 | Interface | SPI |
| 17 | Response time | 10us |
| 18 | Contrast ratio | 2000:1 |
| 19 | Brightness | 120NITS |
| 20 | VDD | 3.3V |
| 21 | Backlight | / |
| 22 | Backlight color | / |
| 23 | LED lifetime | / |
| 24 | Voltage for LED | / |
| 25 | Current for LED | / |
| 26 | Consumption | / |
| 27 | Module weight | 1.54g |
| 28 | Drive IC | SSD1306 |
| 29 | Interface connect type | solering type |
| 30 | Surface tratement | / |
| 31 | Pin number | 20PINS |
| 32 | Warranty | 12 months |
| 33 | Packing material | Box |
| 34 | Shipment | Express*Air*Sea |
| Part 2:Operation Speficifactions | ||
| 1 | Operature Temperature | -40----70℃ degrees |
| 2 | Storage Temperature | -40----85℃ degrees |
| Part 3:Touch panel | ||
| 1 | Touch | No touch |
| Part 4:Lead time | ||
| 1 | Sample | 2 working days |
| 2 | Mass production | 2-4 weeks |
.
LCD PICS
OLED structure
Board structure
