11.6inch 1366*768 IPS Lcd Panel Module Full Viewing Angle Lvds Screen With 400nits Brightness
US$ 25.00 - 35.00
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Wilcon
Model Number:
SW116A-SV3
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
7inch 250nits 1024*600 Lvds Interface IPS Panel Touch Screen With RTPUS$ 20 - 30MOQ: 1 Piece -
4.8inch 540*960 560nits Sunlight Readable IPS Lcd Display Panel With MIPI InterfaceNegotiableMOQ: 1 Piece
-
10.1inch Lvds 350nits 1280*800 IPS Screen Touch Panel With USB CTPNegotiableMOQ: 1 Piece
-
10.1inch Lvds 350nits 1280*800 IPS Screen Touch Lcd Panelwith I2C Interface CTPNegotiableMOQ: 1 Piece
-
10.1inch 350nits 1280*800 Tft IPS Lcd Display Screen With Lvds InterfaceNegotiableMOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
Wilcon
Model Number
SW116A-SV3
Type
Other, TFT, TFT
11.6inch IPS lcd display
LCD specification
| Part 1:LCD parameters | ||
| 1 | Product name | 11.6inch IPS lcd display |
| 2 | Model number | SW116A-SV3 |
| 3 | Size | 11.6INCH |
| 4 | Type | TFT |
| 5 | Viewing angle | IPS |
| 6 | Display scale | 16:9 |
| 7 | Display mode | Normally Black, Transmissive |
| 8 | Resolution | 1366*768 |
| 9 | Piexel pitch | 0.1875*0.1875 |
| 10 | Dimension | 268*158*4.5mm |
| 11 | Active area | 256.125*144 |
| 12 | Color | 16.7M |
| 13 | Color arragement | RGB |
| 14 | Interface | LVDS |
| 17 | Response time | 25ms |
| 18 | Contrast ratio | 800:1 |
| 19 | Brightness | 400cd/m2 |
| 20 | VDD | 3.3V |
| 21 | Backlight | LED |
| 22 | Backlight color | White |
| 23 | LED lifetime | 15000hours |
| 24 | Voltage for LED | 3.3V |
| 25 | Current for LED | 300mA |
| 26 | Consumption | / |
| 27 | Module weight | / |
| 28 | Drive IC | / |
| 29 | Interface connect type | connector type |
| 30 | Surface tratement | Anti glare |
| 31 | Pin number | 50PINS |
| 32 | Warranty | 12 months |
| 33 | Packing material | Box |
| 34 | Shipment | Express*Air*Sea |
| Part 2:Operation Speficifactions of 10.4inch tft lcd display | ||
| 1 | Operature Temperature | 0----50℃ degrees |
| 2 | Storage Temperature | -20----60℃ degrees |
| Part 3:Touch panel | ||
| 1 | Touch | RTP ,CTP is available,depends on customer need |
| Part 4:Lead time for 10.4inch tft lcd display | ||
| 1 | Sample | 2 working days |
| 2 | Mass production | 2-4 weeks |
.
11.6inch IPS lcd display
11.6inch IPS lcd display structure
