Specifications
We supply glass processing machine like water jet machine, water jet glass cutting machine, marble water jet machineS&K CNC Water Jet Cutting Machine Waterjet is CE Quality
cnc water jet cutting machine waterjet
1-Specification of Water Jet Machine:
Model |
SKWJ-1012 |
SKWJ-2014A |
SKWJ-2514A |
SKWJ-2518A |
SKWJ-3015A |
SKWJ-3018A |
SKWJ-4018 |
Cutting table Size |
1.8mx 1.4m |
2.1mx 1.6m |
2.7mx 1.6m |
2.7mx 2.0m |
3.2mx 1.7m |
3.2mx 2.0m |
4.2mx 2.1m |
Cutting stroke |
1.0mx1.2mx0.12m |
1.9mx1.4mx0.12m |
2.5mx1.4mx0.12m |
2.5mx1.8mx0.12m |
3.0mx1.5mx0.12m |
3.0mx1.8mx0.12m |
4.0mx1.8mx0.12m |
Traverse speed |
10m/min |
10m/min |
10m/min |
10m/min |
10m/min |
10m/min |
10m/min |
CNC control |
servo |
servo |
servo |
servo |
servo |
servo |
servo |
Machine Features Size |
1.8mx2mx1.5m |
2.9mx2.2mx1.8m |
3.5mx2.8mx1.8m |
3.5mx2.8mx1.8m |
4.3mx2.3mx1.8m |
4.0mx2.8mx1.8m |
5.3mx3.4mx1.8m |
Cutting Accuracy |
0.1mm |
0.1mm |
0.1mm |
0.1mm |
0.1mm |
0.1mm |
0.1mm |
cnc water jet cutting machine waterjet
2- ULTRA-HIGH PRESSURE SYSTEM
A- Controlled by PLC;
B- Bigger Attenuator,stable pressure;
C- There are Air Cooling and Water Cooling to be chosen.
cnc water jet cutting machine waterjet
3- NUMERICAL CONTROL SYSTEM.
A- LE SOFTWARE
It runs on WINDOWS XP system and has many advanced functions such as auto-cuttingin and out, auto nesting,simulating
the track before working, calculating the cutting time and the cost;
B- Window XP waterjet soffware The design is user-friendly;
C- Pc-base name brand industrial computer, G-code style controller;
D- Simple electric design, PLC control;
E- Quickly show a tool path, avoid wrong cutting;
F- Add up HP time;
G- Automatic shown the length of cutting. Easy to caculate the price of cutting for customer;
H- You can set X.Y axis travel sot spacing. Avoiding cutting head exceed the travel;
I- You can set servio motor start frequency;
J- The system can auto generate thd CNC processing program;
K- Commine AutoCAD drawing with technique data;
L- Achieve the communication between PC and CNC.
cnc water jet cutting machine waterjet
4- SUPERCHARGER ( SUPPER INTENSIFIER)
A- Advanced & Reliable Electron-shift;
B- 60,000 PSI Ultra-high Pressure;
C- ESL HP Sed.
---------------------------------------------------------------------------------------------
cnc water jet cutting machine waterjet
cnc water jet cutting machine waterjet
cnc water jet cutting machine waterjet
GUARANTEE/ AFTER SALE SERVICE
Guarantee Period |
one year |
Best Service |
long-term technical support |
Other Supports |
English Software & Instruction, Detailed Videos |
cnc water jet cutting machine waterjet
