Specifications
ultrasonic distance measurer owner's manualA.size:0.55-18.288m/2-16ft
ction:Measurement
C.power:1*9v
D.frequency:40kHZ
Wintape Measuring Tape Co., Ltd , We are a professional manufacturer of measuring tape , steel tape measure , fiberglass tape measure, tailor tape and tyvek paper measuring tape . Our tape measure can be customized with your company name or LOGO. Tailor Measuring Tape is made with fiberglass and soft PVC plastics, fiberglass can make the tape more strong and flexile.
WinTape has a wide selection of tape measure to suit your needs. A custom tape measure is a great way to promote your company at your next trade show or other. Contact us for all your special, wholesale, and promotional tape measure needs.
Why choose us ?
Specification
1.power 1*9v
2.unit of measurement feet or meters
3.accuracy 0.5%+1digit (2-60ft)
ing frequency 40khz
ing temperature 32 to109.4 degree Celsius
6.range 2 to 602ft (0.55-18.288m)
7.specification are subject to change and improvement without notice
How to use
1.Turning the measure on/off
To turn on the measur ,press READ.The measurer turns itself off if no key is pressed within about 30 seconds .
2.Taking a measurement
(1)press measurer to turn on the unit ,the laser light on, the distance between the measure and the point you measured appears.
(2)hold the bottom of measure flat against a wall .about halfway between the floor and ceiling ,be sure there is a clear path to the point you want to measure and that your head or hands do not block the front of the measurer.
3.Set the base of measurement the initial base is bottom base, the bottom unit icon will display ,if you press the set key ,will change to top base ,and the top unit icon will diplay.
4.Adding /substracting after measurer the length M1,then press +or - and you can get the result M1+M2 or M1-M2.
5.Metric and imperial the initial unit is metric ,press the FEET /MEATER key the unit can switch betwen METRIC and IMPERIAL.
6.Calculating area and volume to find the area and volume of a room , measure the length.and press X,measure the width then press X ,then the square jcon and data of area appears ,measure the Height and press X the cubic and the data of volume appears.
Caution
1.The laser emitted from the unit is visible laser of 650nm wavelength
2.Don't stare into the laser beam and also don't shoot laser beam to any other's eyes.
3.Class II laser product Output < 1mw.
4.Corresponding label is affixed on the back of the unit.
5.If you do not plan to use the measure for a moonth or more ,remove the battery ,Batteries can leak chemicals that can destroy electronic parts.
