Specifications
Adopted Italy motor reducer, Japanese clutch and electrical components to controllifting/descending
HC-D2 Standard/Economic semi-automatic screen printer
- 1. Adopted Italy motor reducer, Japanese clutch and electrical components to control lifting/descending and printing; the printing is controlled by frequency conversion, pressure by pneumatic, which enhanced the reliability of action, and prolonged the service life; the stainless steel table is precise and durable.
- 2. It is suitable to the precise screen printing on varieties of flat materials, such as plastic, glass, metal, paper etc; and is widely applied to the industry of color paper, packing & printing, circuit board, thin film switch, scutcheon, etc.
- 3. The electrode, reducer, clutch, and the electrical control system adopted imported components. Print speed can be adjusted by frequency conversion, the structure of stainless steel table surface is aluminum honeycomb.
- 4. The pneumatic blade switching is fast and stable.
- 5. It is automatic and synchronous screen separation.
- 6. The suction force of working table is adjustable.
- 7. The sensitive safe bar ensures the personnel safety.
Specification:
Max. printing area A:60*80(cm) B:50*70(cm)
Max. size of screen frame0 A:88*110(cm) B:78*100(cm)
Frame size of printing table A79*91(cm) B: 69*81(cm)
Max. printing speed A:1100(pc/h) B1200(pc/h)
Printing thick 0-10(mm)
Height of synchronous screen separation 0-15(mm)
Working table L/T adjustment ±10(mm)
Power supply (3 phases, 4 lines) 380/50-60V/HZ
Power A: 1.8 (kw) B: 1.5(kw)
Air pressure 0.4-0.6(mm)
Outline size A140*130*120(mm) B: 130*120*120(mm)
N.W A: 400(kg) B: 350(kg)
