Manual Screen Printing Machine

Specifications

HC-D3 Manual Screen Printer

Feature

1.)Adopted imported high pressure suction device, ensure accurate positioning. The stainless steel table surface of aluminum honeycomb structure is durable, with mechanical style suction system.

2.)Simple and safe operation; the adjustable screen plate positioning adjusts the screen plate fast and accurately.

3.)Suitable to the precise screen printing on varieties of flat materials, such as plastic, glass, metal, paper, etc.

4.)Widely applied to the industry of color paper, packing & printing, circuit board, thin film switch, scutcheon etc.

5.)Specification:

Printing area:                   70*50(cm)

Max. size of screen frame:     60*80(cm)

Up/down, L/R adjustment:    3 (cm)

Power:                              0.55 (kw)

Outline size L*W*H:              120*100*120(cm)

Weight:                              87(kg)

Screen printing mcachine
single color

6.) Single color
